Ready-Lite CADACSDOW Emergency Light Unit, 9-1/2 Inch Height x 6-5/8 Inch Width, NiMH, 90 Min Runtime
- MPN: CADACSDOW
- UPC: 624050089701
- PPN: T-B-CADACSDOW
CAD
$1033.33
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Battery Unit, Battery Type: NiMH, dual-mode AC/self-powered & diagnostic (-20°C to 40°C), Colour: off white, 120/347VAC, Battery Run Time: 90 minutes
Features
- Nema-3R Rated for indoor/outdoors wet and Damp locations: -20°C to 50°C SD model
- Patent Pending design for easy installation: wall-mount backplate includes electrical wire box with snap-on connector
- Patent Pending light engine: four power LEDs with redundant connections and very wide beam
- Clear polycarbonate lens of reduced size (3-inch x 1.5-inch), shockabsorbent and UV-resistant
- Battery: high-temperature rated, Nickel-Metal Hydride technology
- Power consumption in stand-by: less than 5W Self-Test and diagnostic functions, operated by micro-controller
Specifications
North American Specifications (UNSPSC)
| UNSPSC | 39111709 Emergency light unit |
|---|---|
| Brand Name | Ready-Lite |
| Application | Institutional, Commercial |
| Voltage Rating | 120/347VAC |
| Battery Runtime | 90 minutes |
| Material | Housing: Die-cast aluminum |
| Environmental Conditions | -20°C to 40°C |
| IGCC | 3940 Emergency light unit |
|---|---|
| Type | Battery Units |
| Standard | CSA |
| Battery | NiMH |
| Size | 9-1/2 Inches Height x 6-5/8 Inches Width |
| Mounting | Wall |
| Color | Off-white |
Packaging
| Inner Quantity | 1 |
|---|---|
| Outer Quantity | 6 |
| Weight Uom | 5 lbs. Each |
| Inner Dimensions (inches) | 1x1x.1 |
|---|---|
| Outer Dimensions (inches) | 1x1x1 |
European Specifications (ETIM)
| ETIM | EC001957 Emergency luminaire |
|---|---|
| Material housing | Aluminium |
| Monitoring equipment | Automatic self test |
| Voltage type | AC |
| Width | 168mm |
| Mounting method | Wall build on |
|---|---|
| Colour housing | White |
| Battery quality | NiMH |
| Nominal voltage | 120-347V |
| Height/depth | 240mm |
