Brady LSZH-C-094-WT PermaSleeve Low Smoke Zero Halogen Heat Shrink Tubing 0.094 Inch Dia x 70 ft L, White
Brady LSZH-C-094-WT PermaSleeve Low Smoke Zero Halogen Heat Shrink Tubing 0.094 Inch Dia x 70 ft L, White
- MPN: LSZH-C-094-WT
- UPC: 754473941796
- PPN: BRD-LSZH-C-094-WT
- UNSPSC: 55121612
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$147.52/ EA
Description
PermaSleeve Heat Shrink Tubing is engineered for thermal transfer printing and is ideal for use in wire identification.
Features
- Suitable for use in applications that require low smoke, halogen free, flame retardant markers
Specifications
Specifications
- Applications
- Wire and Cable Labeling
- Color
- White
- Finish
- Matte
- Label/Media Format
- Roll
- Print Technology
- Thermal Transfer
- Printer and Label Applications
- Wire & Cable
- Shrink Ratio
- 2:1
- Trade Name
- PermaSleeve®
- Label Properties
- Heat Shrink Sleeves
- Material Properties
- Flame-retardant; Heat-shrinkable; Low-smoke; Zero-halogen
- SAP B-Number
- B-7641
- Diameter as Supplied (mm/cm/m)
- 2.4 mm
- Dimensions (Metric)
- 4.6 mm H
- Height (in/ft/yd)
- 0.182 in
- Inside Core Diameter (in/ft/yd)
- 1.625 in
- Maximum Service Temperature °F
- 221 °F
- Maximum Wire Diameter (mm/cm/m)
- 2 mm
- Minimum Service Temperature °C
- -55 °C
- Minimum Wire Diameter (in/ft/yd)
- 0.047 in
- Minimum Wire Gauge
- 24 AWG
- Recovered Diameter (mm/cm/m)
- 1.2 mm
- Recovered Wall Thickness (mm/cm/m)
- 0.53 mm
- Roll Length (mm/cm/m)
- 21.34 m
- Sleeve Size (mm/cm/m)
- 2.4 mm Dia x 21.34 m L
- Wire Gauge Range
- 24 AWG to 20 AWG
Brand NameBrady®
Enables Industry ComplianceBS6853 (1999) Vehicle Category 1a; EN 45545-2, Requirement Set R22/R23, Vehicle Category HL3; Method 215K; MIL-STD-202G; RoHS Compliant
For Use with PrinterBBP®72 Label Printer; BradyPrinter i7100; THT 3" Core Printer
Primary Noun, Basic FunctionHeat Shrink Tubing
Printable SidesSingle-Side Printable
Recommended RibbonR6406
Suggested Ribbon SeriesR6000 Halogen Free; R6600
Brady Material NumberB-7641
MaterialHeat-shrink Polyolefin
Resistance PropertiesChemical-Resistant; Self-Extinguishing; Smear-Resistant
Diameter as Supplied (in/ft/yd)0.094 in
Dimensions0.182 in H
Dimensions 20.182 in H
Height (mm/cm/m)4.6 mm
Maximum Service Temperature °C105 °C
Maximum Wire Diameter (in/ft/yd)0.08 in
Maximum Wire Gauge20 AWG
Minimum Service Temperature °F-67 °F
Minimum Wire Diameter (mm/cm/m)1.2 mm
Recovered Diameter (in/ft/yd)0.047 in
Recovered Wall Thickness (in/ft/yd)0.021 in
Roll Length (in/ft/yd)70 ft
Sleeve Size (in/ft/yd)0.094 in Dia x 70 ft L
Wire Diameter Range0.047 in to 0.08 in
Regulatory Information
- Contains CA PROP 65 Substance
- No - Does not contain
- Contains Heavy Metal(s)
- No - Does not contain
- EU RoHS Compliance
- Pass 2011/65/EU
- SDS Safety Data Sheet required
- No = MSDS/SDS is not required
Contains CA PROP 65 SubstanceNo
DOT Regulated ProductNo = not regulated by DOT
EU RoHS CompliantYes
