ABB CA5-13N CA5-13N Auxiliary Contact Block
- MPN: CA5-13N
- UPC: 888614154667
- PPN: ABB-CA5-13N
- UNSPSC: 39121500
CAD
$146.14
/ EA
Available to Order from Manufacturer
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
CA5-13N Auxiliary Contact Block
Specifications
Additional
| Rated Frequency | 50/60 Hz |
|---|---|
| Rated Short-time Withstand Current | 140 A for 0.1 s, 100 A for 1 s |
| Rated Operational Current DC-13 (Ie) | (24 V) 6 A / 144 W, (48 V) 2.8 A / 134 W, (72 V) 1 A / 72 W, (110 V) 0.55 A / 60 W, (125 V) 0.55 A / 69 W, (220 V) 0.30 A / 66 W, (250 V) 0.3 A / 75 W |
| Maximum Mechanical Switching Frequency | 3600 cycles per hour |
| Number of Poles | 4 |
| Number of Auxiliary Contacts NC | 3 |
| Product Net Height | 47 mm |
| Product Net Depth / Length | 39 mm |
| Mounting Type | Front mounting |
| Terminal Type | Screw Terminals |
| Degree of Protection | Auxiliary Terminals IP20 (IEC 60529) |
| Pilot Duty UL/CSA | A600Q300 |
| RoHS Information | 2CMT2021-006277 |
| WEEE B2C / B2B | Business To Business |
| ETIM | EC000041 - Auxiliary contact block |
| Object Classification Code | K |
| Suitable For | N22EN31EN40ENL22ENL31ENL40ETNL22ETNL31ETNL40E |
| Rated Operational Voltage | Auxiliary Circuit 690 V |
|---|---|
| Rated Operational Current AC-15 (Ie) | (500 V) 2 A, (690 V) 2 A, (24/127 V) 6 A, (220/240 V) 4 A, (380/400 V) 3 A |
| Maximum Electrical Switching Frequency | 1200 cycles per hour |
| Minimum Switching Capacity | A9 ... A75 17/5 VLT4KA95 ... A110 24/50 VLT4K |
| Number of Auxiliary Contacts NO | 1 |
| Power Loss | 0.1 W per pole at rated conditions |
| Product Net Width | 43 mm |
| Product Net Weight | 0.06 kg |
| Mounting Position | Front face |
| Material | Accessories for Block Contactors |
| Short-Circuit Protective Devices | Auxiliary Circuit - gG Type Fuses 10 A |
| Rated Insulation Voltage | 690 V (IEC 60947-5-1), 600 V (UL/CSA) |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Customs Tariff Number | 85389099 |
| eClass | V11.0 : 27371302 |
| Mechanical Durability | 10 million |
