Schneider Electric LXMMCAPC020S100 cable, Lexium MC12, connection module, power connection, 2.0m

MPN: LXMMCAPC020S100
PPN: SCH-LXMMCAPC020S100

$194.17

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

The cable is part of Lexium MC12 multi carrier range, a modular transportation system. This cable ensure transmission of power between connection modules and power supplies. It is equipped with an elbowed M23 connector. It is 2m long. It measures 2m long, It weighs 0.5kg. This modular system is for machine applications and consists of long stator motors, on which multiple carrier units can be moved independently from each other. This offer is certified by CE, UKCA, RCM, TÜV Zertifizierung, China RoHS, and WEEE. To create a transportation system, associate long stator motor segments, Guide rails, carriers, communication/power interconnects and cables. This cable links connection module to power connector (indfeed). Next generation transport system with unprecedented simplicity in installation and commissioning. Lexium MC12 multi carrier is an innovative transport system for moving, positioning or grouping objects in machines for discrete processes.

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Germany

Physical Attributes

Cable Length	2 m

Important Information Attributes

Persona Type Ids	EU, OM
Local Data Status	Publishable
Return Indicator	N
Stock Policy	2
Traceability	No
Scope Perimeter	At least in Europe
Reach Full Compliance Status Id	CONTAINS_SVHC
Rohs Eur In Scope	No
Rohs Eur Conformity Date	2140
China Rohs In Scope	Yes
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	3
Function Option	Advanced
Market Segmentation	Industrial
Connector Type	M23
Product Or Component Type	cable
Returnability	No
Pep Code	ENVPEP1112048EN
Accessory / Separate Part Type	cable
Nbr. Of Units In Pkg.	1
Take-back	No
Customs Code	8544429090

Persona Type Names	End User, Original Equipment Manufacturer
Local Publishable Date	2026-01-12
Stocking Flag	Y
Serviceability	No
Weee Scope	Out
Reach Full Compliance Status	Reference contains Substances of Very High Concern above the threshold
Reach Compliance Directive	Reference contains Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant By Exemption
Rohs Eur Full Compliance Status	Compliant By Exemption
China Rohs Label	5
Without Single Use Plastic	No
Tier Id	3
Function Option Id	ADVANCED
Market Segmentation Id	INDUSTRIAL
Product Kit Identifier	N
Product Availability	Non-Stock - Not normally stocked in distribution facility
Range Of Product	Lexium MC12 multi carrier
Sustainable Packaging	No
Accessory / Separate Part Category	connection accessories
Accessory / Separate Part Designation	power cable
Package Weight(Lbs)	700 g
Warranty (In Months)	18

Environment Attributes Main

Take Back	No
China Rohs Regulation	X
Environmental Disclosure	ENVPEP1112048EN
Packaging Made With Recycled Cardboard	Yes
Reach Regulation	Reference contains Substances of Very High Concern above the threshold

Recycled Metal Content At Cr Level	0 %
Mercury Free	Yes
Eu Rohs Directive	Compliant By Exemption
Packaging Without Single Use Plastic	No
Pep Code	ENVPEP1112048EN
