nVent Hoffman CEPH1624 Cable Entry Plate 58mm x 150mm, 16 Entry, Black, Plastic, IP66
- MPN: CEPH1624
- UPC: 783510583071
- PPN: HOF-CEPH1624
- UNSPSC: 39121324
CAD
$38.88
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
CEPH-kabelgenomföring ger en mycket platt, utrymmesbesparande professionell kabelgenomföring med en mycket tät tätning. Den speciella formen på membrankongenomföringen hjälper till att säkerställa optimal dragavlastning
Features
- Description: Fast, cost-effective cable entry with a tight seal for incoming cables and/or pneumatic conduits inside an enclosure. Can be affixed with screws or the built-in snap-in system that works for wall thicknesses of 1.5 to 2.5 mm.
- Finish: Black
- Flammability: UL94 V-0
- Material: Polyamide 6.6 / TPE
- Pack quantity: 1 pc
- Protection: IP66, NEMA 1, 4x, 12 (Indoor use only)
- Temperature resistance: -40°C to +90°C
Documentation & Downloads
Specifications
Key Specifications
| BABA | Contact Manufacturer |
|---|---|
| Cable Entry | (2) 3.2 - 6.3 mm |
| Height (H) | 58 |
| Depth (D) | 12 |
| Material | Plastic |
| Color | Black |
| Weight | 0.1 |
| Cable Entry Quantity | 16 |
|---|---|
| Cutout Size | 36 x 112 |
| Width (W) | 149.6 |
| Product Family | Cable Manager |
| Finish | Untreated |
| Operating Temperature | -40 |
| Works With | NEMA |
