Schneider Electric XEND2641 Harmony XAC Double Contact Block, 40mm, 2-Spring Return, 1 C/O + 1 NO
- MPN: XEND2641
- PPN: SCH-XEND2641
CAD
$196.82
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
The Harmony XAC Double Contact Block from Schneider Electric is designed for seamless integration into automation and control systems. This robust component features a 40mm size, equipped with two spring return mechanisms, providing reliable performance and enhanced efficiency. With its configuration of one changeover (C/O) and one normally open (NO) contact, this contact block is ideal for a variety of pilot device applications, ensuring efficient operation in demanding environments. As part of Schneider Electric's commitment to quality and innovation, this contact block offers a reliable solution for those looking to streamline their control systems.
Documentation & Downloads
Specifications
Additional
- Conventional Enclosed Thermal Current
- 10 A
- Rated Impulse Withstand Voltage
- 6 kV IEC 60947-1
- Rated Operational Power DC (DC-13)
- 31 W (48 V), 35 W (120 V), 48 W (24 V) IEC 60947-5-1 appendix C
- Contact Configuration
- 1 C/O + 1 NO
- Mechanical Durability
- 1,000,000 cycles
- Vibration Resistance
- 15 gn (10-500 Hz) IEC 60068-2-6
- Contact Block Type
- Double
- Connections - Terminals
- Screw clamp, 1 x 2.5 mm² or 2 x 1.5 mm², with or without cable end
- Ambient Air Temperature for Storage
- -40 to 70 °C (-40 to 158 °F)
- Standards Compliance
- CSA C22.2 No 14, IEC 60947-5-1, EN 60947-5-1
- EU RoHS Compliance
- Pro-active compliance, Free of SVHC
Rated Insulation Voltage400 V IEC 60947-1
Short-Circuit Protection10 A fuse protection cartridge gG
Rated Operational Power AC (AC-15)140 VA (24 V), 210 VA (48 V), 640 VA (127 V), 680 VA (230 V) 50/60 Hz IEC 60947-5-1
Contact OperationStaggered, Slow-break
Shock Resistance100 gn IEC 60068-2-27
Type of Operator2 spring return
Mounting of BlockFront mounting
Ambient Air Temperature for Operation-25 to 70 °C (-13 to 158 °F)
Material and ConstructionMercury Free, Toxic Heavy Metal Free
China RoHS CompliantYes
Country of OriginCzech Republic (CZ)
