Schmersal 101209414 Junction Box M12 8-Pole, IP65/IP67, 16.5 mm Width, 1 Nm Torque
- MPN: 101209414
- PPN: SCM-101209414
CAD
$54.28
/ EA
Available to Order from Manufacturer
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Junction Box M12 8-Pole, IP65/IP67, 16.5 mm Width, 1 Nm Torque
Documentation & Downloads
Specifications
Key Specifications
| Length | 43 mm |
|---|---|
| Height | 16.5 mm |
| Width | 16.5 mm |
|---|
Electrical data
| Rated operating voltage | 30 VDC |
|---|
| Operating current | 4,000 mA |
|---|
Mechanical data - Dimensions
| Width | 16.5 mm |
|---|---|
| Diameter of the ISO-thread | M12 |
| Height | 16.5 mm |
|---|
Mechanical data - connector side A
| Connector latching | Screw locking |
|---|---|
| Material of the handle | Plastic, TPU |
| Material of the gland | Metal, CuZn, nickel-plated |
|---|
General data
| Versions | Terminating plug |
|---|---|
| Gross weight | 20 g |
| Connector (electric) | 1 x Male connector, 8-pole |
|---|
Ambient conditions
| Degree of protection | IP65 | IP67 |
|---|
| Ambient temperature | -25 ... +75 °C |
|---|
Mechanical data
| Tightening torque, maximum | 1 Nm |
|---|
Accessory
| Recommendation (product combination) | Sensors and solenoid interlock |
|---|
