Brady DAT-119-502-10 DATAB Series Coated Cloth Labels with Permanent Adhesive, 0.375" H x 0.375" W, Pack of 10000 Labels
- MPN: DAT-119-502-10
- UPC: 662820273196
- PPN: BRD-DAT-119-502-10
- UNSPSC: 55121612
CAD
$542.99
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
This durable and economical polymer coated cloth features repositionable rubber-based adhesive for ease of use.
Features
- Matte polymer coated cloth features permanent rubber adhesive and is dot matrix printable
- B-502 labels have good smudge resistance, oil and water resistance and fade resistance
- Operating temperature of -40°F to 176°F (-40°C to 57°C)
Documentation & Downloads
Specifications
Key Specifications
- Applications
- Circuit Board Labeling; Component and Equipment Labeling
- Brand Name
- Brady®
- Compatible Surface Types
- Low Surface Energy
- Enables Industry Compliance
- ASTM B 117; ASTM D 1000; ASTM D 2979; ASTM G 155
- For Use with Printer
- Dot Matrix Printers
- Primary Noun, Basic Function
- Label
- Printer and Label Applications
- Wire & Cable
- Quantity per Roll
- 10000
- Ribbon Series
- R2000; R5000
- Suggested Ribbon Series
- R5000
- Total Quantity
- 10000
- Adhesive Type
- Permanent Rubber Based
- Brady Material Number
- B-502
- Material
- Vinyl Cloth
- SAP B-Number
- B-502
- Dimensions (Metric)
- 9.53 mm W x 9.53 mm H
- Height (in/ft/yd)
- 0.375 in
- Horizontal Repeat
- 0.5 in
- Label/Tape Size (in/ft/yd)
- 0.375 in H x 0.375 in W
- Maximum Service Temperature °F
- 176 °F
- Maximum Wire Diameter (mm/cm/m)
- 3.05 mm
- Minimum Application Temperature °F
- 50 °F
- Minimum Service Temperature °F
- -40 °F
- Minimum Wire Diameter (mm/cm/m)
- 1.27 mm
- Printable Area Height (mm/cm/m)
- 9.53 mm
- Sign Size-General
- 0.375 in x 0.375 in
- Thickness (in/ft/yd)
- 0.0096 in
- Vertical Repeat
- 0.5 in
- Web Width (in/ft/yd)
- 8.9 in
- Width (in/ft/yd)
- 0.375 in
- Wire Diameter Range
- 0.05 in to 0.12 in
Board ApplicationThrough Hole - Top
ColorWhite
Corner TypeRounded Corners
FinishMatte
Label/Media FormatPack
Print TechnologyDot Matrix
Printer CompatibilityDot Matrix
Quantity per Row16
ShapeSquare
Total Qty per Pack10000 Label(s) / Pack
Trade NameDATAB®
After ProcessYes, this material will work with this application
Label PropertiesPermanent Adhesive Labels
Resistance PropertiesAbrasion-Resistant; Chemical-Resistant; Corrosion-Resistant; Humidity-Resistant; Oil-Resistant; Smear-Resistant; UV-Resistant; Water-Resisitant
Dimensions0.375 in H x 0.375 in W
Dimensions 20.375 in H x 0.375 in W
Height (mm/cm/m)9.53 mm
Horizontal Repeat (mm)12.70 mm
Maximum Service Temperature °C80 °C
Maximum Wire Diameter (in/ft/yd)0.12 in
Minimum Application Temperature °C10 °C
Minimum Service Temperature °C-40 °C
Minimum Wire Diameter (in/ft/yd)0.05 in
Printable Area Dimensions (Metric)9.53 mm H x 9.53 mm W
Printable Area Width (mm/cm/m)9.53 mm
Size - Width (mm)9.53 mm
Thickness (mm/cm/m)0.244 mm
Vertical Repeat (mm)12.70 mm
Web Width (mm/cm/m)226.06 mm
Width (mm/cm/m)9.53 mm
Regulatory Information
- Contains CA PROP 65 Substance
- Yes Contains-Label not req.
- Contains Heavy Metal(s)
- Unavailable
- EU RoHS Compliance
- Pass 2011/65/EU(Pass 2015/863)
- SDS Safety Data Sheet required
- No = MSDS/SDS is not required
Contains CA PROP 65 SubstanceNo
DOT Regulated ProductNo = not regulated by DOT
EU RoHS CompliantYes
