Bussmann ATC-2 Blade Fuse 32 Vdc 2A 1 kAIC Non-Indicating Grey
- MPN: ATC-2
- UPC: 051712813433
- PPN: BUS-ATC-2
CAD
$3.20
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Blade Fuse 32 Vdc 2A 1 kAIC Non-Indicating Grey
Features
- Engineered for targeted circuit protection, this 2-amp fast-acting blade fuse reliably handles up to 32VDC. It provides the exact, sensitive overcurrent defense required for delicate electronics, ensuring your low-voltage systems remain completely safe from short circuits without accidental, premature blowing
- Built to withstand tough real-world conditions, this fuse operates flawlessly across a wide temperature range of -40 C to 100 C (-40 F to 212 F) in up to 95% non-condensing humidity. The high-durability housing material resists melting and deformation, making it highly reliable for demanding under-hood automotive applications and industrial control environments.
- This heavy-duty blade fuse is UL Recognized for use in low-voltage control circuits and carries a 1kA interrupting rating to safely halt major electrical faults. Fully lead-free, halogen-free, and RoHS compliant, it meets all modern environmental safety standards for commercial fleet, marine, and industrial applications.
Documentation & Downloads
Specifications
Additional
- Voltage
- 32 Vdc
- Interrupt Rating
- 1 kAIC
- Size
- .75 in. L x .49 in. W x .2 in. H
- Material
- Tin-plated zinc terminals and element, Polycarbonate housing
- Certifications
- UL Listed
- Fuse Indicator
- Non Indicating
- Application
- Automotive
Amperage2A
Fuse TypeBlade fuse, ATC blade fuse
Weight.1 lb
Housing Flammability RatingUL 94
ComplianceRoHS Compliant, SAE J1171 Ignition Protection
ColorGrey
