Bussmann ATC-3 Automotive Blade Fuse 32 Vdc, 3A, 1 kAIC, Violet, UL Listed
- MPN: ATC-3
- UPC: 051712703215
- PPN: BUS-ATC-3
CAD
$2.50
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Automotive Blade Fuse 32 Vdc, 3A, 1 kAIC, Violet, UL Listed
Features
- The Bussmann ATC-3 features a precise 3A current rating and a 32V DC voltage rating, engineered to provide strict overcurrent protection for low-amp automotive circuits, marine accessories, and HVAC control boards. By blowing predictably when current exceeds 3 amp thresholds, it intercepts electrical spikes before they can fry expensive, delicate down-line electronic components or cause thermal damage.
- Designed as a fast-acting, non-indicating blade fuse, this unit utilizes a highly responsive zinc element that breaks the circuit rapidly upon sensing an overcurrent condition. This fast-blow characteristic minimizes the duration of short circuits and faults, giving you the immediate, reliable interruption needed to defend modern vehicle modules, sensors, and low-voltage control loops from sustained electrical stress.
- Featuring premium tin-plated zinc terminals and elements, the ATC-3 delivers exceptional electrical conductivity while fighting off terminal oxidation and atmospheric corrosion. This high-grade material selection ensures a stable, low-resistance connection within the fuse holder over years of service, preventing the premature voltage drops or erratic behavior often caused by lower-quality, non-plated alternatives.
- Engineered with a heavy-duty polycarbonate housing that carries a UL 94 flammability rating, this fuse maintains structural and electrical integrity across a wide operating temperature range from -40C to 100C (95% non-condensing relative humidity). This environmental resilience makes it ideal for rigorous, high-heat under-hood automotive applications as well as freezing outdoor low-voltage equipment enclosures.
Documentation & Downloads
Specifications
Additional
- Voltage
- 32 Vdc
- Interrupting Rating
- 1 kAIC
- Fuse Indicator
- Non Indicating
- Length
- 1.63 in.
- Height
- .38 in.
- Color
- Violet
- Terminal Material
- Tin-plated zinc
- Certifications
- UL Listed, RoHS Compliant
- Warranty
- Not Applicable
Amperage3 A
TypeBlade fuse
Operating Temperature Range-40 C to 100 C
Width1.38 in.
Weight.03 lb
Housing MaterialPolycarbonate
Element MaterialTin-plated zinc
ApplicationAutomotive
