Bussmann DFJ-35 High Speed Fuse 35A 600 Vac 450 Vdc Non Indicating Class J Melamine Tube
- MPN: DFJ-35
- UPC: 051712653336
- PPN: BUS-DFJ-35
CAD
$81.77
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Eaton Bussmann series DFJ high speed fuse, 600 Vac or less, 450 Vdc or less, 35A, 200 kAIC at 600 Vac, 100 kAIC 450 Vdc, Non Indicating, High speed fuse, Clip-lock, Class J, Melamine tube
Features
- Engineered with a robust 35-amp capacity and rated up to 600Vac/dc, this high-performance drive fuse provides reliable, heavy-duty protection for variable speed drives (VFDs) and sensitive solid-state power controllers. It ensures your industrial machinery runs safely without premature tripping under normal high-voltage operations.
- Featuring high-speed, UL Class J performance, this fuse delivers exceptional current limitation by clearing faults in a fraction of a cycle. This ultra-fast response cuts down let-through energy, drastically minimizing the risk of catastrophic damage to your expensive VFDs, SCRs, and silicon rectifiers during a short-circuit event.
- Boasting an impressive 200 kAIC at 60 V AC (and 100 kAIC at 450 V DC) interrupting rating, the DFJ-35 is built to safely isolate severe overcurrent faults without exploding or compromising the panelboard.
- Designed to strict UL Class J dimensional standards, this compact cylindrical fuse easily fits standard open blocks, finger-safe holders, or disconnect switches. Its standardized small footprint saves valuable control panel space while guaranteeing a secure, vibration-resistant physical connection in demanding factory environments.
Documentation & Downloads
Specifications
Additional
- Amperage
- 35 A
- Interrupt Rating
- 100 kAIC 450 Vdc
- Size
- 1 in Width x 1 in Length/Depth x 2.4 in Height
- Material
- Melamine tube
- Certifications
- UL Listed, CE Marked
Voltage600 Vac or less, 450 Vdc or less
Fuse ClassClass J
Product Weight0.17 lb
ConnectionClip-lock
Fuse IndicatorNon Indicating
