Bussmann FWA-35A21F High Speed Fuse 35A 500 Vac/Vdc 100 kAIC Non Indicating Ferrule X Ferrule
- MPN: FWA-35A21F
- UPC: 051712795258
- PPN: BUS-FWA-35A21F
CAD
$68.15
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
High Speed Fuse 35A 500 Vac/Vdc 100 kAIC Non Indicating Ferrule X Ferrule
Specifications
Key Specifications
| Fuse Indicator | Non Indicating |
|---|---|
| Construction Size | Other |
| Connection | Ferrule end X ferrule end |
| Amperage Rating | 35A |
| Utilization category | aR (accompanied semiconductor protection) |
| Type | High speed fuse |
| Breaking Capacity | 200 A |
| With Striker | No |
| Pre Arc (I2T) | 75 |
| Application | DC common bus, DC drives, power converters/rectifiers and reduced voltage starters |
| Voltage Type | AC/DC |
| Interrupt Rating | 100 kAIC |
|---|---|
| Clearing (I2T) | Clearing at 150V: 800 |
| Release Characteristic | Other |
| Frequency Rating Maximum | 62 HZ |
| Watt Losses | 4.5W |
| Fuse Shape | cylindrical |
| Amperage Rating Numeric | 35 A |
| Frequency Rating Minimum | 45 HZ |
| Voltage Rating | 500 Vac, 500 Vdc |
| Voltage Rating Numeric | 150 V |
| Packaging Type | Standard |
General
| UPC | 051712795258 |
|---|---|
| Product Length/Depth | 51 MM |
| Product Width | 21 MM |
| Warranty | Not Applicable |
| Certifications | CSA Certified |
| EAN | 5027590499248 |
|---|---|
| Product Height | 21 MM |
| Product Weight | 55.3 G |
| Compliances | CE Marked |
