Bussman

Bussman FWH-325A High Speed Fuse 325A RMS, 4.52 Inch Width, 1.69 Inch Length, 1000 Vac

High Speed Fuse 325A RMS, 4.52 Inch Width, 1.69 Inch Length, 1000 Vac
High Speed Fuse 325A RMS, 4.52 Inch Width, 1.69 Inch Length, 1000 Vac
High Speed Fuse 325A RMS, 4.52 Inch Width, 1.69 Inch Length, 1000 Vac
High Speed Fuse 325A RMS, 4.52 Inch Width, 1.69 Inch Length, 1000 Vac
  • MPN: FWH-325A
  • UPC: 051712153782
  • PPN: BUS-FWH-325A

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$153.82/ EA

Specifications

Specifications

Height
1.61 IN
Width
4.52 IN
Type
FWH, North American style
Voltage Rating
1000 Vac, 800 Vdc
Interrupt Rating
200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc
Mounting
Stud
Clearing (I2T)
Clearing at 500V: 63800
Pre Arc (I2T)
13700
Length1.69 IN
Weight.52 LB
ApplicationDC common bus, DC drives, power converters/rectifiers, reduced voltage starters
Amperage Rating325A RMS
ConnectionBlade end X blade end
Packaging TypeStandard
Fuse IndicatorNon Indicating
Watt Losses53W
