Bussmann FWH-225A High Speed Fuse 225A RMS, 1.69 Inch Length, 4.52 Inch Width
- MPN: FWH-225A
- UPC: 051712153751
- PPN: BUS-FWH-225A
CAD
$150.88
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Eaton Bussmann series FWH high speed fuse, 1000 Vac, 800 Vdc, 225A RMS, 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
Features
- Engineered for demanding power environments, this high-speed semiconductor fuse handles a continuous 225A RMS current rating to easily support your DC drives, power converters, and rectifiers. It eliminates nuisance tripping under standard operational loads while maintaining tight, localized protection for your most sensitive solid-state electronics.
- Featuring an impressive 200 kAIC breaking capacity at 500 VAC and 50 kAIC at 500 VDC, this very fast-acting fuse safely isolates severe short-circuit events. It minimizes dangerous arc flash hazards and drastically limits destructive let-through energy, shielding expensive downstream components from catastrophic failure.
- Built with a standardized cylindrical ceramic body measuring 1.69 inches in length by 4.52 inches in width, this center-bolted tag model ensures a seamless drop-in replacement. The robust blade-end terminal design allows for secure stud-mounting and a direct bolt-down connection, preventing loose terminal connections that cause thermal overheating.
- This industrial-grade electrical fuse is fully UL Recognized, CSA Certified, and CE Marked, guaranteeing it complies with strict international safety and performance regulations. You can pass facility inspections and maintenance audits with total confidence knowing you are utilizing premium, code-compliant circuit protection.
Documentation & Downloads
Specifications
Additional
- Amperage
- 225A RMS
- Interrupt Rating
- 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc
- Pre Arc (I2T)
- 4600
- Length
- 1.69 in
- Height
- 1.61 in
- Mounting
- Stud
- Type
- FWH, North American style
- Application
- DC common bus, DC drives, power converters/rectifiers, reduced voltage starters
Voltage1000 Vac, 800 Vdc
Watt Losses39W
Clearing (I2T)23300 at 500V
Width4.52 in
Weight0.52 lb
ConnectionBlade end X blade end
Fuse IndicatorNon Indicating
