Bussmann FWH-500A High Speed Fuse 500A RMS, 750 Vac/Vdc, 2.8 Inch Height, 5.3 Inch Width
- MPN: FWH-500A
- UPC: 051712150217
- PPN: BUS-FWH-500A
CAD
$281.50
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
High Speed Fuse 500A RMS, 750 Vac/Vdc, 2.8 Inch Height, 5.3 Inch Width
Documentation & Downloads
Specifications
Key Specifications
| Height | 2.8 IN |
|---|---|
| Width | 5.3 IN |
| Type | FWH, North American style |
| Voltage Rating | 750 Vac, 750 Vdc |
| Interrupt Rating | 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc |
| Mounting | Stud |
| Clearing (I2T) | Clearing at 500V: 149000 |
| Pre Arc (I2T) | 29200 |
| Length | 2.17 IN |
|---|---|
| Weight | .92 LB |
| Application | DC common bus, DC drives, power converters/rectifiers, reduced voltage starters |
| Amperage Rating | 500A RMS |
| Connection | Blade end X blade end |
| Packaging Type | Standard |
| Fuse Indicator | Non Indicating |
| Watt Losses | 84W |
