Bussmann FWA-500A High Speed Fuse 500A AC/DC, 89 MM Length, 200 kAIC Interrupt Rating
- MPN: FWA-500A
- UPC: 051712795425
- PPN: BUS-FWA-500A
CAD
$195.42
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
High Speed Fuse 500A AC/DC, 89 MM Length, 200 kAIC Interrupt Rating
Documentation & Downloads
Specifications
Key Specifications
- Height
- 25.4 MM
- Width
- 25.4 MM
- Type
- Fuse
- Voltage Rating
- 500 Vac/dc (35-800A only)
- Amperage Rating
- 500A
- Interrupt Rating
- 200 kAIC Vac (70-1000A), 20 kAIC at 150 Vdc (70-800A), 100 kAIC at 80 Vdc (70-1000A)
- Construction Size
- Other
- Packaging Type
- Standard
- Fuse Shape
- centre-bolted tags
- Insulated Metal Gripping Lugs (IMGL)
- No
- Voltage Type
- AC/DC
- Rated switching capacity
- 200 A
Length89 MM
Weight192 G
Applicationprotection of DC common bus, DC drives, power converters/rectifiers and reduced voltage starters
Voltage Rating Numeric150 V
Amperage Rating Numeric500 A
ConnectionBlade end X blade end
MountingStud
Clearing (I2T)120000
Fuse IndicatorNone
Pre Arc (I2T)39000
Watt Losses35
