Bussmann NON-2 Supplemental One-Time Fuse, 2 A, Class H, Ferrule End x Ferrule End, 50 kAIC at 250 Vac
- MPN: NON-2
- UPC: 051712300025
- PPN: BUS-NON-2
CAD
$10.40
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Basic protection 250V NON Class K5 and H
general purpose, non-current-limiting, one-time fuses.
Features
- Engineered for basic overcurrent protection, this cartridge fuse handles up to 2 A at 250 Vac and 125 Vdc. It is the perfect fit for safeguarding lighting networks, heating circuits, and other light-duty electrical lines that are not prone to high motor starting surges.
- Boasting an impressive 50 kAIC symmetrical interrupting rating at both 250 Vac and 125 Vdc, this fuse clears high fault currents reliably. This means your facility stays fully protected against severe circuit faults, mitigating the risk of structural damage or localized fires.
- Measuring exactly 0.56 inches in diameter by 2 inches in length, this standard ferrule-end cartridge seamlessly swaps into your existing infrastructure. This precise form factor eliminates installation frustration and minimizes maintenance downtime during routine physical replacements.
- As a Class K5 / Class H general-purpose, non-current-limiting fuse, it provides stable, economical protection where massive energy suppression isn't necessary. It offers a highly cost-effective choice for simple power distribution blocks and branch circuits with lower available short-circuit currents.
- This one-time, non-indicating electrical fuse acts as a physical fail-safe by opening definitively under fault conditions. Once it trips, it requires a complete swap out, giving you absolute visual and mechanical certainty that the compromised line is totally isolated before you re-energize.
- Fully UL Listed (Guide JDDZ, File E4274) and CSA Certified, this component satisfies stringent municipal and industrial building standards.
Documentation & Downloads
Specifications
Additional
- Interrupting Rating
- 50 kA at 250 Vac, 50 kA Vdc
- Voltage Rating
- 250 Vac, 125 Vdc
- Connection Type
- Ferrule End x Ferrule End
- Product Diameter
- 0.56 in
- Special Features
- Non current limiting
Amperage2 A
ClassClass H
Product Length2 in
ComplianceCE Marked
