Bussmann NON-1 One-Time Fuse, 1 A, Non-Indicating, 50 kAIC at 125 Vdc, Ferrule End Connection
- MPN: NON-1
- UPC: 051712300018
- PPN: BUS-NON-1
CAD
$10.82
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
One-Time Fuse, 1 A, Non-Indicating, 50 kAIC at 125 Vdc, Ferrule End Connection
Features
- Engineered as a 1-amp, non-current-limiting "one-time" single-element fuse, this unit delivers standard supplemental protection by quickly opening the circuit when an overcurrent is detected. Because it reacts precisely to normal overloads without any built-in time delay, it is the ideal component for safeguarding low-draw, light-duty utility applications from catastrophic board damage.
- Built with versatile voltage capacities handling up to 250V AC and 125V DC, this Class K5/H fuse easily fits into diverse commercial panel designs. This dual-rated capability simplifies stock profiles for facility maintenance electricians, allowing them to confidently drop the same reliable fuse into light-duty heating controls, basic resistor networks, or general-purpose office infrastructure
- Boasting a robust 50,000-amp interrupting rating (AIC) at maximum voltage, this cartridge fuse is built to withstand high-energy fault conditions without shattering its casing. This exceptional thermal containment protects nearby terminal blocks, instrumentation, and maintenance personnel from the dangerous blast and arc flash hazards of sudden short circuits.
- Measuring a standardized 0.56-inch diameter by 2.0-inch length (14.2 times 50.8 mm), this cylindrical ferrule-terminal fuse slides into a massive ecosystem of standard general-purpose fuse clips and panels. This exact mechanical compatibility provides a drop-in cross-reference for older or legacy light-duty circuits, completely eliminating the need for costly panel retrofitting or block upgrades.
Documentation & Downloads
Specifications
Additional
- Amperage
- 1 A
- Voltage Rating
- 250 Vac, 125 Vdc
- Fuse Indicator
- Non-indicating
- Length
- 0.56 in
- Width
- 0.56 in
- Compliance
- CE Marked
- Special Features
- Non current limiting
Interrupt Rating50 kAIC at 125 Vdc, 50 kAIC at 250 Vac
Fuse TypeOne-time
ConnectionFerrule end x ferrule end
Height2 in
Weight0.35 lb
ClassClass H, Class K5
