Bussmann REN-15 Renewable Fuse 15A 250V Super Lag Time Lag 10 kAIC Class H Ferrule End Connection
- MPN: REN-15
- UPC: 051712100151
- PPN: BUS-REN-15
CAD
$47.27
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Renewable Fuse 15A 250V Super Lag Time Lag 10 kAIC Class H Ferrule End Connection
Features
- Engineered for ultimate economy in industrial environments, this Class H cartridge fuse features a highly practical, renewable design. When an overload occurs, you only need to replace the internal link (Bussmann LKN-15) rather than the entire assembly, slashing your long-term maintenance overhead and keeping critical replacement parts stocked at a fraction of the cost.
- Built with advanced Super-Lag time-lag characteristics, this 15 Amp fuse easily withstands transient, non-damaging temporary current surges and inductive inrush spikes common in commercial machinery. This specific time-delay engineering eliminates nuisance tripping and keeps your downstream operations humming, while still providing robust short-circuit protection when an actual fault occurs.
- The industry-standard ferrule-end design measures exactly 0.56 inches in diameter by 2 inches in length (14.22mm x 50.8mm). This precise physical envelope ensures seamless drop-in compatibility with standard holder mounts, traditional clip terminations, and existing low-voltage electrical distribution panels without requiring expensive hardware retrofits.
- The fuse is UL Listed and rated for up to 250 VAC, making it fully compliant for installation in standard branch circuits and control setups. Boasting a 10 kA (10,000 AIC) interrupting rating, it is explicitly optimized for electrical systems where available fault currents are within lower-level thresholds, ensuring robust circuit protection where it counts.
Documentation & Downloads
Specifications
Additional
- Amperage
- 15A
- Interrupt Rating
- 10 kAIC
- Length
- 2 in
- Width
- 0.56 in
- Connection
- Ferrule end x ferrule end
- Application
- Industrial and commercial structures
Voltage250V
Fuse TypeTime lag, Non current-limiting, Super lag
Height0.56 in
Weight0.55 lb
ClassClass H
