Hubbell Premise Wiring SFFSCSGNOW Fiber Optic Connector SC Simplex, .58" x .76", Green, Flush Mount
- MPN: SFFSCSGNOW
- UPC: 662620241203
- PPN: HBL-SFFSCSGNOW
- UNSPSC: 43223310
CAD
$22.48
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Fiber Optic Connectors, Snap-Fit, Flush, SC Simplex, Zircon Sleeves, Green, Office White Housing.
Features
- Snap Fit
- Office White Housing
- Flush
- SC Simplex
- Green Adapter
- Standard Product
Specifications
Key Specifications
- Country of Origin
- Taiwan
- Width
- 0.500 in
- Size
- .58" X .76"
- Color
- Green
- Insertion Loss
- 0.75 dB
- Repeatability
- 0.1 dB
- Service Life
- 500 matings
- Standard
- Telcordia GR-326-CORE;TIA-568-C.3;TIA-604 FOCIS-3
- Temperature Rating
- 0C to 70C
- Mounting Type
- Flush
- Class Code
- A68
- Freight Class Code
- 06168002
- Image Actual Or Representative
- A
- Replaced Catalog Number
- SFFSCSGNLA
- Material - Mounting Hardware
- Snap-In, Keystone
- Base Unit of Measure
- EA
- Carton - Gross Weight per Pack
- 0.250 lb.
- Carton - Pack Description
- Carton
- Carton - Total Units
- 25
- Each - Pack Description
- Each
- NAICS Code
- 3342104145
Color - HousingOffice White
Industry Standard(s)Telcordia GR-326-CORE;TIA-568-C.3;TIA-604 FOCIS-3
ApplicationData Outlet
Fiber Size125 Micron
MountingFlush
Return Loss55
Special FeaturesStandard Product
Sub BrandOptiChannel
ConnectivityReceptacle
StyleSC Simplex
Description - InvoiceFIBER, SNAP-FIT,FLSH,SC SMPLX,GN,ZIRC,OW
Harmonization Code8536700000
MSDS FlagNo
Sub Class CodeHPWALL2
MaterialCeramic
BOX SIZE4.300x7.900x5.500 (in)
Carton - Number of Sub Packs25
Carton - SCC-14 Next Lower Level Sub Pack662620241203
Case Weight0.700 lb.
Lowest Level UOMEach
Certifications
- EU RoHS Indicator
- No
