Brady 109158 Food Industry Pipe Markers for Steam - Laminated Polyester on High Performance/High Visibility Label Carrier, Style 4, 0
Brady 109158 Food Industry Pipe Markers for Steam - Laminated Polyester on High Performance/High Visibility Label Carrier, Style 4, 0
- MPN: 109158
- UPC: 754473673901
- PPN: BRD-109158
- UNSPSC: 55121737
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$18.43/ EA
Description
Laminated B-681 polyester seals in and protects graphics.
Features
- Industrial grade self-adhesive protects against bacteria or moisture trapping behind the pipe marker
- Style 4 pipe markers measure 1-1/8 in. x 7 in., comes with four markers per card and fit pipe diameter 3/4 in. to 2-3/8 in.
- All stock markers meet ASME (ANSI) when used with arrow tape
- For clean room applications, the material liner should be removed prior to entering the clean room
Specifications
Specifications
- Brand Name
- Brady®
- Compatible Surface Types
- High Surface Energy
- Primary Noun, Basic Function
- Pipe Marker
- Adhesive Type
- Permanent Acrylic
- Indoor or Outdoor Use
- Outdoor Use
- Material
- Polyester with Polyester Overlaminate
- SAP B-Number
- B-681
- Maximum Service Temperature °C
- 110 °C
- Minimum Application Temperature °C
- -18 °C
- Minimum Outside Pipe Diameter (in/ft/yd)
- 0.75 in
- Minimum Service Temperature °F
- -40 °F
- Thickness (in/ft/yd)
- 0.0051 in
ColorWhite on Green
Enables Industry ComplianceANSI A13.1-2007
Quantity per Card or Sheet4
Brady Material NumberB-681
LaminatedLaminated
Resistance PropertiesAbrasion-Resistant; Chemical-Resistant
Maximum Outside Pipe Diameter (in/ft/yd)2.375 in
Maximum Service Temperature °F230 °F
Minimum Application Temperature °F0 °F
Minimum Service Temperature °C-40 °C
Overall SizeFits Pipes 0.75" Dia. Thru 2.375in Dia.
Thickness (mm/cm/m)0.13 mm
Regulatory Information
- Contains CA PROP 65 Substance
- No - Does not contain
- Contains Heavy Metal(s)
- No - Does not contain
- EU RoHS Compliance
- Pass 2011/65/EU
- SDS Safety Data Sheet required
- No = MSDS/SDS is not required
Contains CA PROP 65 SubstanceNo
DOT Regulated ProductNo = not regulated by DOT
EU RoHS CompliantYes
