Brady 108818 Food Industry Pipe Markers for Water - Laminated Polyester on High Performance/High Visibility Label Carrier, Style 4, 0
- MPN: 108818
- UPC: 754473670504
- PPN: BRD-108818
- UNSPSC: 55121737
CAD
$17.29
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Laminated B-681 polyester seals in and protects graphics.
Features
- Industrial grade self-adhesive protects against bacteria or moisture trapping behind the pipe marker
- Style 4 pipe markers measure 1-1/8 in. x 7 in., comes with four markers per card and fit pipe diameter 3/4 in. to 2-3/8 in.
- All stock markers meet ASME (ANSI) when used with arrow tape
- For clean room applications, the material liner should be removed prior to entering the clean room
Documentation & Downloads
Specifications
Key Specifications
- Brand Name
- Brady®
- Compatible Surface Types
- High Surface Energy
- Primary Noun, Basic Function
- Pipe Marker
- Adhesive Type
- Permanent Acrylic
- Indoor or Outdoor Use
- Outdoor Use
- Material
- Polyester with Polyester Overlaminate
- SAP B-Number
- B-681
- Dimensions 2
- 1.125 in H x 7 in W
- Maximum Outside Pipe Diameter (in/ft/yd)
- 2.375 in
- Maximum Service Temperature °F
- 230 °F
- Minimum Application Temperature °F
- 0 °F
- Minimum Service Temperature °C
- -40 °C
- Overall Size
- Fits Pipes 0.75" Dia. Thru 2.375in Dia.
- Sign Size-General
- 1.125 in x 7 in
- Thickness (mm/cm/m)
- 0.13 mm
ColorWhite on Green
Enables Industry ComplianceANSI A13.1-2007
Quantity per Card or Sheet4
Brady Material NumberB-681
LaminatedLaminated
Resistance PropertiesAbrasion-Resistant; Chemical-Resistant
Dimensions1.125 in H x 7 in W
Height (in/ft/yd)1.125 in
Maximum Service Temperature °C110 °C
Minimum Application Temperature °C-18 °C
Minimum Outside Pipe Diameter (in/ft/yd)0.75 in
Minimum Service Temperature °F-40 °F
Roll/Tape Size (in/ft/yd)1.125 in H x 7 in W
Thickness (in/ft/yd)0.0051 in
Width (in/ft/yd)7 in
Regulatory Information
- Contains CA PROP 65 Substance
- No - Does not contain
- Contains Heavy Metal(s)
- No - Does not contain
- EU RoHS Compliance
- Pass 2011/65/EU
- SDS Safety Data Sheet required
- No = MSDS/SDS is not required
Contains CA PROP 65 SubstanceNo
DOT Regulated ProductNo = not regulated by DOT
EU RoHS CompliantYes
