Mersen A2Y3-1 Form 600 Fuse 250V 3A Type 1 Ferrule Mount, 500V DC, 0.56 Inch Diameter
- MPN: A2Y3-1
- UPC: 782001901479
- PPN: FER-A2Y3-1
CAD
$70.27
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Mersen Form 600 fuses are the original current-limiting fuses, predating all the standards. Their 500V DC rating (through 600A) is a useful feature for special fusing applications. Form 600 fuses provide a high degree of current limitation in AC and DC applications. Types 1 and 3 are dimensionally interchangeable with Class H and K fuses. Types 4 and 5 have unique rejection dimensions and are not interchangeable.
Specifications
Key Specifications
- Rated voltage AC UL
- 250 V
- Frequency (Hz)
- 50/60 Hz
- AC or DC
- AC/DC
- AC Max I.R./Breaking Capacity: I1
- 200 kA
- Connection/Terminal Type
- Ferrule
- L/R (ms)
- 10 ms
- Weight
- 0.04 lb
Rated voltage DC UL500 V
Ampere Rating3 A
MountingClip
Connection/Terminal MaterialTin-Plated Copper
Body/Insulating MaterialGMG
Length2 in
