Brady THT-55-434-1 Gloss Metallized Polyester Labels, 2" H x 4" W
- MPN: THT-55-434-1
- UPC: 662820302872
- PPN: BRD-THT-55-434-1
- UNSPSC: 55121612
CAD
$415.99
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Metallized Polyester (B-434) labels are designed for applications that use barcodes, alphanumerics, graphic symbols and logos and require nameplate-like quality.
Features
- Glossy, light gray finish gives labels a rating and serial plate appearance
- Labels are designed to withstand numerous solvents and variable temperatures when applied to various surfaces
- UL approved;CSA accepted
- Service temperature of -40 to 194° F (-40 to 90° C)
Documentation & Downloads
Specifications
Key Specifications
- Applications
- Asset Tracking; General Identification; Inventory and Inspection Labeling
- Bulk Part
- Not a Bulk Part
- Compatible Surface Types
- High Surface Energy
- Diagram
- Icon 3 (triangle)
- Finish
- Gloss
- Label/Media Format
- Roll
- Print Technology
- Thermal Transfer
- Printer Compatibility
- BBP12; BBP11; BP1244; BP1344; BP2461; BP3481; BP6441; MVP200; MVP300; 300XPlusII; 360XPlusII; 600XPlusII; PR200Plus; PR300Plus; PR600Plus; IP300; IP600; i7100; i5100
- Quantity per Roll
- 1000
- Recommended Ribbon
- IP-R6007; R6007
- Shape
- Rectangle
- Total Qty per Pack
- 1000 Label(s) / Roll
- Trade Name
- MetaLabel
- Brady Material Number
- B-434
- Material
- Metallized Polyester
- Resistance Properties
- Abrasion-Resistant; Humidity-Resistant; UV-Resistant; Weather-Resistant
- Core Diameter (mm/cm/m)
- 76.20 mm
- Dimensions (Metric)
- 101.60 mm W x 50.80 mm H
- Height (in/ft/yd)
- 2 in
- Label/Tape Size (in/ft/yd)
- 2 in H x 4 in W
- Maximum Service Temperature °F
- 194 °F
- Minimum Service Temperature °F
- -40 °F
- Printable Area Height (mm/cm/m)
- 50.8 mm
- Sign Size-General
- 2 in x 4 in
- Thickness (in/ft/yd)
- 0.004 in
- Vertical Repeat
- 2.125 in
- Web Width (mm/cm/m)
- 106.68 mm
- Width (mm/cm/m)
- 101.6 mm
Brand NameBrady®
ColorSilver
Corner TypeRounded Corners
Enables Industry ComplianceASTM D 1000; ASTM D 2979; ASTM G 155; CSA Approved; UL Recognized
For Use with PrinterBBP®81 Label Printer; BRADY IP® Series Label Printer; BradyPrinter i5100; BradyPrinter i7100; BRADYPRINTER PR Plus Series Label Printer; THT 3" Core Printer
Primary Noun, Basic FunctionLabel
Printer and Label ApplicationsGeneral Identification; Inspection Repair; Rating & Name Plates
Printer Compatibility (Print)BBP12; i7100; i5100
Quantity per Row1
Ribbon SeriesR6000HF
Suggested Ribbon SeriesR4800; R4900; R6000 Halogen Free; R6200
Total Quantity1000
Adhesive TypePermanent Acrylic
Label PropertiesMetallic Labels; Permanent Adhesive Labels
Material PropertiesMetallic Appearance
SAP B-NumberB-434
Dimensions2 in H x 4 in W
Dimensions 22 in H x 4 in W
Height (mm/cm/m)50.80 mm
Maximum Service Temperature °C90 °C
Minimum Service Temperature °C-40 °C
Printable Area Dimensions (Metric)50.8 mm H x 101.6 mm W
Printable Area Width (mm/cm/m)101.6 mm
Size - Width (mm)101.60 mm
Thickness (mm/cm/m)0.102 mm
Vertical Repeat (mm)53.98 mm
Width (in/ft/yd)4 in
Regulatory Information
- Contains CA PROP 65 Substance
- Yes Contains-Label not req.
- Contains Heavy Metal(s)
- No - Does not contain
- EU RoHS Compliance
- Pass 2011/65/EU(Pass 2015/863)
- SDS Safety Data Sheet required
- No = MSDS/SDS is not required
Contains CA PROP 65 SubstanceNo
DOT Regulated ProductNo = not regulated by DOT
EU RoHS CompliantYes
