Burndy YGA26N Grounding Irreversible Compression Terminals, Copper, 3.22 Inch Length, 2/0 AWG

MPN: YGA26N
UPC: 781810226148
PPN: BUR-02005464

$59.97

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

Grounding Irreversible Compression Terminals, Copper, 3.22 Inch Length, 2/0 AWG

Specifications

Key Specifications

Color Code	Black
Die Index	13 12;348
Material	Copper
Plated	N
Trade Name	HYLUG™
UPC	781810226148
Dimension - B Length fraction	1-4/9 in 1-1/3 in
Dimension - Hole Size inch	0.56 in
Dimension - L Length Overall mm	82 mm 78 mm
Dimension - N inch	0.62 in
Dimension - Strip Length inch	1-9/16
Conductor - Copper Str Size Range	2/0 AWG (Test 1) 1/0
Certification - ETL	No
Certification - UL Recognized	No
Industry Standard(s)	UL467
UL Listed	No

Connector Type	Terminal
Item Type	4D
Physical Attribute - Number of Crimps Required	2
Plating Type	Unplated
Type	Terminals
UPC 12 Digit	7818102261488 7818102261311
Dimension - B Length inch	1.45 in 1.35 in
Dimension - Hole Size mm	14 mm
Dimension - Length Overall inch	3.22 in 3.06 in
Dimension - Outside Diameter inch	0.56 in 0.51 in
Conductor - Copper Str Size	2/0 AWG (Test 1) 1/0
Certification - CSA Approved	No
Certification - UL Listed Direct Burial	Yes
Certification - cULus	No
Standards - RoHS Compliance Status	UI
