Jonard Tools MS-426 Jonard Tools MS-426 Mid Span Slit & Ring Tool (5.8mm-12mm)
- MPN: MS-426
- UPC: 811490019973
- PPN: JTL-MS-426
CAD
$273.21
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Groove Sizes: 5.8-6.4 mm | 7.8-8.4 mm | 9.8-10.4 mm | 11.2-12 mm
Features
- Consists of 4 precision slitting grooves and 4 precision ring grooves ranging in size from 5.8 mm to 12 mm
- One side of the tool performs radial/ring cuts and the other side slits the cable (longitudinal cut)
- Compact design weighing less than 8 oz with included tethering hole makes it perfect to use in tight spaces or on the go
- Indicator line on top of the unit indicates the position of the blade for accurate slitting and ringing
- This tool was specially designed for use on Prysmian ESMF Optical Mini FlexTube® cables and other similar style cables, including Corning equivalent cables
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Taiwan, Province of China
- Length
- 3.94 Inch
- Number of Slitting Grooves
- 4
- Number of Ringing Grooves
- 4
- Cable Type
- Thick-walled Jackets (up to 2.0 mm thick)
Cut TypeSlit, Ring
Width4.72 Inch
Height8.5 Inch
Weight0.54 Lbs.
Cable Diameter5.8 mm-12 mm
