Hubbell Wiring Device-Kellems 07310005 Kellems I-Grips, 0.85-1.00 Inch, Galvanized Steel Mesh
- MPN: 07310005
- UPC: 783585332185
- PPN: HBL-07310005
- UNSPSC: 39121719
CAD
$122.74
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Kellems Wire Management, I-Grips, .85- 1.00", Galvanized
Features
- Controls cable arc-of-bend
- Provides heavy-duty strain relief
- Easily attached to Insulgrip plug and connector body
- Plastic Coated Mesh
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | China |
|---|---|
| Cable Diameter Range | 0.85 in-1.00 in |
| Industry Standard(s) | UL Listed |
| Application | Light Duty |
| Special Features | Plastic Coated Mesh |
| Type | Eyelets (2) |
| General Literature Asset 1 Display Text | Pulp & Paper Solutions |
| General Literature Asset 3 Display Text | FOOD & BEVERAGE SOLUTIONS |
| Display Size | Standard Sized |
| Class Code | A52 |
| Freight Class Code | 06168002 |
| Image Actual Or Representative | A |
| Sub Class Code | A52A480 |
| Construction | Woven |
| Base Unit of Measure | EA |
| Carton - Gross Weight per Pack | 1.000 lb. |
| Carton - Pack Description | Carton |
| Carton - Total Units | 20 EA |
| Case Weight | 33.345 lb. |
| Lowest Level UOM | Each |
| Pallet Length | 44.800 in |
| Pallet Width | 48.000 in |
| Approx Breaking Strength | 250 lb. |
|---|---|
| Width | 3.780 in |
| Standards - RoHS Compliance Status | CM |
| Cable Size | .85"-1.00" (2.16-2.54) |
| Standard | UL Listed |
| Weight | 0.164 lb. |
| General Literature Asset 2 Display Text | PULP & PAPER SOLUTIONS |
| Cable Specification | Mesh Length @ Nom. Dia. : 8" (20.32 cm) |
| Style | I-Grips, For Hubbell Devices |
| Description - Invoice | I GRIP, .85-1.0"; GALV |
| Harmonization Code | 7326200090 |
| MSDS Flag | No |
| Material - Mounting Hardware | Mounts on Cord Grip |
| Material | Galvanized Steel Mesh for Insulated Cables, Plastic Coated |
| BOX SIZE | 3.100x22.200x5.100 (in) |
| Carton - Number of Sub Packs | 20 |
| Carton - SCC-14 Next Lower Level Sub Pack | 783585332185 |
| Case - Total Units | 100 EA |
| Each - Pack Description | Each |
| Pallet Height | 48.000 in |
| Pallet Weight | 384.000 lb. |
| NAICS Code | 3359323114 |
