Hubbell Premise Wiring HBLTT545RB TrukTrak Modular Cable Protection System, 5 Channel, 25 Inch, 13 lbs.
- MPN: HBLTT545RB
- UPC: 783585537245
- PPN: HBL-HBLTT545RB
CAD
$859.78
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
TrukTrak Modular Cable Protection System, 5 Channel, 25 Inch, 13 lbs.
Specifications
Additional
| Channels | 5 Channel |
|---|---|
| Length | 25 in. (635 mm) |
| Maximum Load | 9,200 lbs (40,921 N) @ 48 C |
| Width | 20 in. (508 mm) |
| Material | Cast polyurethane |
| Hinge Material | Reinforced fiberglass |
| Color | blue-yellow |
| Product Line | hbltt5a-diagram |
| Weight | 13 lbs. (5.9 kg) |
|---|---|
| Maximum Load | 20,150 lbs (89,627 N) @ 21 C |
| Height | 2.31 in. (57.2 mm) |
| Channel Width | 1.25 in. (31.8 mm) |
| Channel Height | 1.25 in. (31.8 mm) |
| Operating Temperature | -40 F to +120 F (-40 C to +49 C) |
| Safety Symbols | Per ANSI Z535.3-1991 |
| TrukTrak Variety | 45 deg Left Turn |
