Hubbell

Hubbell ATS-00950 ATS-00950 (former catalog number ATS-LP-N-BHJ-P)

ATS-00950 (former catalog number ATS-LP-N-BHJ-P)
  • MPN: ATS-00950
  • UPC: 662620435183
  • PPN: HBL-ATS-00950

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$95.86/ EA

Description

ATS-00950 (former catalog number ATS-LP-N-BHJ-P). The AccelTex Solutions bi-directional gas discharge tube lightning arrestor protects outdoor equipment from the buildup and discharge of static electricity that affects the operation and lifespan of your network.

Features

  • Bi-directional Ethernet surge suppressor projects equipment from static discharge
  • Enhances network reliability and equipment lifespan

Specifications

Specifications

Country of Origin
Taiwan
Height
1.5 in
Insulation R-Value
Greater than or equql to 1000 megaohms
Length
4.5 in
Width
2 in
Dielectric Strength
2500 V RMS
Frequency Rating
DC - 5.85 GHz
Installation Type
DIN Rail Mount and L Bracket
Class Code
A62
Harmonization Code
8535400000
Sub Class Code
A62A625
Base Unit of Measure
EA
Dimensions4.5 in x 2 in x 1.5 in
Industry Standard(s)IEC 6019-16
Insulator TypeTeflon
Maximum Discharge Voltage90 V
ApplicationIndoor Wi-Fi, Outdoor Wi-Fi
DurabilityGreater than or equal to 500 Cycles
Impedance50 Ohms
Operating Temperature-40 to 85 °C
Freight Class Code06238000
Image Actual Or RepresentativeA
Technology802.11ac, 802.11ax, 802.11n
Carton - SCC-14 Next Lower Level Sub Pack00662620435183
