Schneider Electric LVCT01204S Split Core Current Transformer 1200A 0.333V 62mm x 201mm
- MPN: LVCT01204S
- PPN: SCH-LVCT01204S
CAD
$232.52
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
This low-voltage split-core current transformer is part of PowerLogic BCPM (Branch Circuit Power Meter). It is Ideal for retrofit applications with Schneider Electric energy meters which accept low voltage current transducer input It is rated for a 1200A circuit. 0.333 V output, size 4. Split core opening is 62 mm x 201 mm.
Documentation & Downloads
Specifications
Key Specifications
- Network Frequency
- 50/60 Hz
- Electrical Connection
- cable 1.8 m AWG 18) 600 V
- Output Voltage
- 0.333 V
- Current Transformer Type
- split core balance
- Device Short Name
- LVCT
Product DestinationBCPM || BCPMSC || Enercept || iEM3000 || EM3500 || EM4200 || EM4900
Accessory / Separate Part Categorymeasurement accessory
[In] Rated Current1200 A
Product Or Component Typecurrent transformer
RangePowerLogic
Complementary
- Measurement Accuracy
- 1 % 10...100 %
Range CompatibilityPowerLogic PowerLogic BCPM BCPMA multi-circuit energy meter || PowerLogic PowerLogic BCPM BCPMB multi-circuit energy meter || PowerLogic PowerLogic BCPM BCPME multi-circuit energy meter || PowerLogic PowerLogic BCPMSC BCPMSCA multi-circuit energy meter || PowerLogic PowerLogic BCPMSC BCPMSCB multi-circuit energy meter || PowerLogic PowerLogic BCPMSC BCPMSCE multi-circuit energy meter || PowerLogic PowerLogic EM3500 EM3502 energy meter || PowerLogic PowerLogic EM3500 EM3550 energy meter || PowerLogic PowerLogic EM3500 EM3555 energy meter || PowerLogic PowerLogic EM3500 EM3560 energy meter || PowerLogic PowerLogic EM3500 EM3561 energy meter || PowerLogic PowerLogic EM4200 EM4235 energy meter || PowerLogic PowerLogic EM4200 EM4236 energy meter || PowerLogic PowerLogic EM4900 EM4904 multi-circuit energy meter || PowerLogic PowerLogic EM4900 EM4908 multi-circuit energy meter || PowerLogic PowerLogic EM4900 EM4914 multi-circuit energy meter || PowerLogic PowerLogic EM4900 EM4928 multi-circuit energy meter || Acti 9 Acti9 iEM3000 iEM3455 energy meter || Acti 9 Acti9 iEM3000 iEM3465 energy meter
Environment
- Ambient Air Temperature For Operation
- -15-60 °C
- Relative Humidity
- 95-95 %
- Height
- internal 139 mm || external 201 mm
- Depth
- 30 mm
Ambient Air Temperature For Storage-40-70 °C
Widthinternal 62 mm || external 151 mm
Net Weight0.87 kg
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- China Rohs Regulation
- X
- Mercury Free
- Yes
- Eu Rohs Directive
- Compliant
- Reach Free Of Svhc
- Yes
Rohs Exemption InformationYes
Toxic Heavy Metal FreeYes
Reach RegulationFree of Substances of Very High Concern above the threshold
