Wiegmann BN4100804CH N4 JIC Continuous Hinge 10X8X4 Carbon Steel - Gray
- MPN: BN4100804CH
- UPC: 786725378357
- PPN: HBL-BN4100804CH
- UNSPSC: 39121324
CAD
$344.68
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
N4 JIC Continuous Hinge 10X8X4 Carbon Steel - Gray
Features
- Designed for use as instrument housings, electrical control enclosures, terminal wiring boxes or electrical junction boxes
- Provides protection where equipment is hosed down, very wet or in outdoor applications.
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | Mexico |
|---|---|
| Color | Ansi-61 Gray Textured |
| Cubic Capacity | 320 cu.in |
| Finish | Textured |
| Mounting | External Mounting Plates |
| Standard | cULus;IEC |
| Width | 8 in |
| Engineering Drawing 3 Display Text | MOD Center Drawings Instructions |
| Material type | Carbon Steel |
| Nema Rating | 4 |
| Class Code | P04 |
| Freight Class Code | 06316009 |
| Image Actual Or Representative | R |
| MSDS Flag | No |
| Returnable Indicator | Yes |
| Sub Class Code | P04P065 |
| UL Listed | Yes |
| Material | Carbon Steel |
| BOX SIZE | 5.700x12.300x10.200 (in) |
| Carton - Number of Sub Packs | 1 |
| Carton - SCC-14 Next Lower Level Sub Pack | 00786725378357 |
| Pallet Height | 44.400 in |
| Pallet Weight | 0.000 lb. |
| NAICS Code | 3359326101 |
| Application | Designed for use as instrument housings, electrical control enclosures, terminal wiring boxes, or electrical junction boxes. Provides protection in areas that are hosed down or very wet or in outdoor applications. |
|---|---|
| Cover Type | Hinged Cover |
| Depth | 4 in |
| Height | 10 in |
| NEMA Rating | 4 |
| Type | Enclosure |
| Weight | 8.5 lb. |
| Finish Type | Textured |
| Mounting Type | External Mounting Plates |
| ARRA Compliant | Contact Manufacturer |
| Description - Invoice | NEMA4,JIC,CS,CH,10X8X4 |
| Harmonization Code | 7326908688 |
| Lead Time | 7 wk |
| Order Multiple | 1 EA |
| Stock Indicator | S - Shelf Stock |
| Latches Type | Clamps |
| Construction | Continuously Welded Seams |
| Base Unit of Measure | EA |
| Carton - Gross Weight per Pack | 8.500 lb. |
| Carton - Pack Description | Carton |
| Carton - Total Units | 1 EA |
| Pallet Length | 40.000 in |
| Pallet Width | 48.000 in |
Certifications
| Buy American Compliant | No |
|---|---|
| Listings | UL, CSA |
| Certified Listed | cULus;IEC |
|---|
