Wiegmann BN4060403CH N4 JIC Continuous Hinge 6X4X3 Carbon Steel - Gray
Wiegmann BN4060403CH N4 JIC Continuous Hinge 6X4X3 Carbon Steel - Gray
- MPN: BN4060403CH
- UPC: 786725378159
- PPN: HBL-BN4060403CH
- UNSPSC: 39121324
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$205.98/ EA
Description
N4 JIC Continuous Hinge 6X4X3 Carbon Steel - Gray
Features
- Designed for use as instrument housings, electrical control enclosures, terminal wiring boxes or electrical junction boxes
- Provides protection where equipment is hosed down, very wet or in outdoor applications.
Specifications
Specifications
- Buy American Compliant
- Contact Manufacturer
- Each - Width
- 6.100 in
- Color
- Ansi-61 Gray Textured
- Cubic Capacity
- 72 cu.in
- Finish
- Textured
- Mounting
- External Mounting Plates
- Standard
- cULus;IEC
- Width
- 4 in
- Finish Type
- Textured
- Nema Rating
- 4
- Class Code
- P04
- Freight Class Code
- 06316009
- Image Actual Or Representative
- R
- MSDS Flag
- No
- Returnable Indicator
- Yes
- Sub Class Code
- P04P065
- UL Listed
- Yes
- Material
- Carbon Steel
- BOX SIZE
- 4.550x7.950x6.100 (in)
- Carton - Number of Sub Packs
- 1
- Carton - SCC-14 Next Lower Level Sub Pack
- 00786725378159
- Pallet Height
- 50.000 in
- Pallet Weight
- 1029.600 lb.
Country of OriginMX
ApplicationDesigned for use as instrument housings, electrical control enclosures, terminal wiring boxes, or electrical junction boxes. Provides protection in areas that are hosed down or very wet or in outdoor applications.
Cover TypeHinged Cover
Depth3 in
Height6 in
NEMA Rating4
TypeEnclosure
Weight4.1 lb.
Mounting TypeExternal Mounting Plates
ARRA CompliantContact Manufacturer
Description - InvoiceNEMA4,JIC,CS,CH,6X4X3
Harmonization Code7326908688
Lead Time21 wk
Order Multiple1 EA
Stock IndicatorS - Shelf Stock
Latches TypeClamps
ConstructionContinuously Welded Seams
Base Unit of MeasureEA
Carton - Gross Weight per Pack4.100 lb.
Carton - Pack DescriptionCarton
Carton - Total Units1 EA
Pallet Length48.000 in
Pallet Width40.000 in
Certifications
- Certified Listed
- cULus;IEC
- Listings
- UL, CSA
EU RoHS IndicatorYes
