Blackburn SAPT 4/0-106 PT 4/0 Aluminum Compression Pin Terminals, 4/0 Stranded, 1/0 Pin Diameter, 6 Inch Length
- MPN: SAPT 4/0-106
- UPC: 783786749126
- PPN: T-B-SAPT 4/0-106
CAD
$69.45
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Aluminum Compression Pin Terminals - SAPT Series, 4/0 Stranded, pin diameter 1/0 (.325), pin length 6, dies TX,76,249,840,11A, barrel insertion 2-1/2 inch.
Specifications
North American Specifications (UNSPSC)
| UNSPSC | 39121432 Electrical terminals |
|---|---|
| Brand Name | Blackburn |
| Special Features | Made from Aluminum which provides high strength and conductivity. Oxide Inhibitor Prevents Oxidation. Metal Sealant Protects Pin/Body from Moisture Intrusion. |
| Connection | Crimp / Compression |
| Material | Aluminum and Copper with Tin-Plated Pin |
| IGCC | 4603 Electrical terminals |
|---|---|
| Type | Aluminum Compression Pin Terminals |
| Application | Connect Aluminum and ACSR to Copper-Alloy Equipment Clamps and Elimate Cold-Flow Problems. |
| Wire Size | Aluminum Stranded 4/0 |
Packaging
| Outer Quantity | 25 |
|---|---|
| Weight Uom | 0.4 lbs. Each |
| Outer Dimensions (inches) | 12.5x12.5x3.5 |
|---|
