Schneider Electric ABR7S11 Plug-in Electromechanical Relay 5 mm 24 V DC 1 NO 500000 Cycles
- MPN: ABR7S11
- PPN: SCH-ABR7S11
CAD
$11.68
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
This product is part of the Modicon ABE7 range, an offer of connection sub-bases for pre-wired system. This is an electromechanical plug-in relays for 24VDC prewired sub-bases. It has 1 NO contact. Its mechanical durability is up to 20000000 cycles. It immunity to microbreaks is up to 1ms. It is used to to control the power along with switching the smaller current values in a control circuit. It is 5mm wide. It weighs 0.005kg. It is suitable into any types of industrial applications needing rapid connection of I/O modules (digital, analog, and counter) to operative parts. It is suitable for use with ABE7R16T111, ABE7R16M111, ABE7P16M111, and ABE7P16T111 sub-bases. It is delivered in 1 package (PCE type) containing 4 units. Modicon ABE7 means greater simplicity to rationalise wiring in automation system equipment.
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | Brazil, China, France, Latvia, United States |
|---|
Complementary Attributes
| Control Circuit Type | DC |
|---|---|
| Maximum Switching Voltage | 250 V AC 50/60 Hz IEC 60947-5-130 V DC IEC 60947-5-1 |
| Maximum Power Dissipation Per Pole | 0.17 W |
|---|---|
| Minimum Switching Current | 100 mA >= 5 V |
Important Information Attributes
| Persona Type Ids | EU, OM, OM8 |
|---|---|
| Electrical Durability | 500000 cycles 2000 mA 230 V AC-12, 500000 cycles 3000 mA 24 V DC-12500000 cycles 400 mA 230 V AC-15, 500000 cycles 500 mA 24 V DC-13 10 ms |
| Local Publishable Date | 2026-01-12 |
| Stocking Flag | Y |
| Weee Scope | In |
| Scope Perimeter | At least in Europe |
| Reach Full Compliance Status Id | NOT_CONTAINING_SVHC |
| Rohs Eur In Scope | No |
| Rohs Eur Conformity Date | 1909 |
| China Rohs In Scope | Yes |
| With Recycled Cardboard | Yes |
| Product Contributes To Saved And Avoided Emissions | No |
| Tier | 1 |
| Function Option | Standard |
| Market Segmentation | Industrial |
| Associated Fuse Rating | 1 A, fast blow |
| Dielectric Strength | 4000 V IEC 60947-1 |
| Mechanical Durability | 20000000 cycles |
| Product Availability | Non-Stock - Not normally stocked in distribution facility |
| Quantity Per Set | set of 4 |
| Returnability | No |
| Threshold Tripping Voltage | 16.8 V 40 °C |
| Width Pitch Dimension | 5 mm |
| [Uc] Control Circuit Voltage | 24 V |
| Drop-out Current | 0.5 mA 20 °C |
| Nbr. Of Units In Pkg. | 1 |
| Take-back | No |
| Customs Code | 8536410050 |
| Persona Type Names | End User, Original Equipment Manufacturer, OEM - Control Panelbuilder |
|---|---|
| Local Data Status | Publishable |
| Return Indicator | N |
| Stock Policy | 2 |
| Weee Product Category | 5 |
| Reach Full Compliance Status | Free of Substances of Very High Concern above the threshold |
| Reach Compliance Directive | Free of Substances of Very High Concern above the threshold |
| Rohs Eur Status | Compliant |
| Rohs Eur Full Compliance Status | Compliant |
| China Rohs Label | 1 |
| Without Single Use Plastic | No |
| Tier Id | 1 |
| Function Option Id | STANDARD |
| Market Segmentation Id | INDUSTRIAL |
| Product Kit Identifier | N |
| Contacts Type And Composition | 1 NO |
| Max Immunity To Microbreaks | 1 ms |
| Operating Rate In Hz | 20 Hz no load0.1 Hz at Ie |
| Product Or Component Type | plug-in electromechanical relay |
| Range Of Product | Advantys Telefast ABE7 |
| Sustainable Packaging | No |
| Weee Label | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| [Ith] Conventional Free Air Thermal Current | 6 A |
| [Uimp] Rated Impulse Withstand Voltage | 6 kV IEC 60947-1 |
| Drop-out Voltage | 2 V 20 °C |
| Package Weight(Lbs) | 5 g |
| Warranty (In Months) | 18 |
Environment Attributes Main
| Product Compatibility | ABE7R16T111, ABE7R16M111, ABE7P16M111, ABE7P16T111 |
|---|---|
| Reach Free Shvc | Yes |
| China Rohs Regulation | X |
| Mercury Free | Yes |
| Packaging Made With Recycled Cardboard | Yes |
| Reach Free Of Svhc | Yes |
| Take Back | No |
|---|---|
| Recycled Metal Content At Cr Level | 0 % |
| Toxic Heavy Metal Free | Yes |
| Eu Rohs Directive | Compliant |
| Packaging Without Single Use Plastic | No |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
General Attributes
| Product Or Component Type | plug-in electromechanical relay |
|---|
| Range Of Product | Advantys Telefast ABE7 |
|---|
ETIM
| ETIM 8 | EC001652 |
|---|
| ETIM 9 | EC001652 |
|---|
Contractual Warranty Attributes
| Warranty Period | 18 months |
|---|
| Warranty | 18 months |
|---|
