Pass & Seymour PTTR26362HGRED PlugTail® 20A 125V Hospital-Grade Duplex Receptacle, Red, 1.5 Inch Width
- MPN: PTTR26362HGRED
- UPC: 785007008593
- PPN: P-S-PTTR26362HGRED
CAD
$35.48
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
PlugTail® Tamper-Resistant Hospital Grade Decorator Receptacle, 20A 125V. PlugTail® devices and connectors mean that device installation is the same regardless of skill level of the installer. The UL-Listed connectors are keyed to ensure proper wiring installation into each receptacle.
Features
- Dual mechanical shutter system to help prevent insertion of foreign objects
- .036 inch thick, brass, triple-wipe power contacts for lasting retention.
- Plated steel wrap strap design for maximum durability and corrosion resistance.
- No exposed terminals create a finger safe application before, during, and after installation.
- Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections.
- Ultrasonically welded polycarbonate connector housing secures terminations and conductors in a UL Listed, finger safe housing.
- Auto-ground clip assures positive ground.
- For covering patents, see www.legrand.us/patents.
- For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here.
- Temperature Rise: Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60°C, minimum -40°C without impact
- PlugTail™ Connector: #12 AWG, THHN, copper conductor, 6"" leads, stripped, solid or stranded, for use with PlugTail Receptacles only
Documentation & Downloads
Specifications
Key Specifications
- Depth
- 0.875 in
- Height
- 2.75 in
- Voltage
- 125.0 V
- Country of Origin
- Mexico
- Indoor/Outdoor
- Indoor
- Is Tamper-Resistant
- Yes
- Number of Receptacles
- 2.0
- Outlet Type
- Straight Blade
- Outlet Type
- Tamper-Resistant
- Application Sector
- Healthcare
- NEMA Configuration Code
- 5-20R
- Color
- Red
- Warranty Type
- 1-Year Limited Warranty
- Operating Temperature Min
- -40.0 °C
Amperage20.0 A
Width1.5 in
StandardFEDSPEC
Number of Wires3.0
Wall Plate IncludedNo
FeaturesDecorator Style
Outlet TypeHospital Grade
Number of PolesDouble Pole
Application SectorCommercial
Connection LocationBack Only
Wire Connection TypePlugTail
Product LinePass & Seymour
Operating Temperature Max60.0 °C
Operating Temperature-40°-60°C
