Mersen R090474 Square Body High-Speed Fuse Protistor® Size 2x122 gR 750VDC IEC 630A With Striker metric threads
- MPN: R090474
- PPN: FER-R090474
CAD
$4810.76
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Mersen DC offers provide a very high performant protection for railway power and auxiliary circuits. Mersen DC Semiconductor fuse-links were developed to provide improved performance required by today's new DC equipment. These fuse-links are typically operated at more elevated temperature than other fuse type, have lower I²t to minimize damage to protected components on short circuits, lower watts loss and longer life.
Specifications
Key Specifications
- Rated voltage DC IEC
- 750 V
- ROHS Compliant
- Yes
- Speed/Characteristic
- gR
- Mounting
- Bolted
- Max. Rated Breaking Capacity DC
- 100 kA
- Indication System
- Yes
- Connection/Terminal Material
- Brass
- Body/Insulating Material
- Ceramic
- Width
- 5.16 in
- Height
- 2.48 in
Ampere Rating630 A
AC or DCDC
Fuse Size2x122
Clearing I2t At Rated Voltage8000 kA²s
Design DetailsgRC
Indication System TypeStriker
Connection/Terminal TypeFlush ends
Power Dissipation at Rated Current Value116 W
Length5.83 in
Weight6.173 lb
