Pass & Seymour 2087W 20A 125V Self-Test GFCI Receptacle with SafeLock Protection
- MPN: 2087W
- UPC: 785007035803
- PPN: P-S-2087W
CAD
$51.38
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Conducts an automatic test every three seconds, ensuring it's always ready to protect. If the device fails the test, the indicator light flashes to signal that the GFCI should be replaced. It also has our proven SafeLock™ Protection feature: if critical components are damaged and protection is lost, power to the receptacle is disconnected.
Documentation & Downloads
Specifications
Additional
| Amperage | 20A |
|---|---|
| NEMA Configuration Number | 5-20R |
| Federal Specification | WC596 |
| cULus Listed | Yes |
| Dimensions | 1.73 in x 1.13 in x 4.2 in |
| Wire Connection Type | Side or internal screw-pressure-plate, back wire |
| Number of Wires | 3 |
| Number of Poles | Double Pole |
| Material | High-impact resistant thermoplastic |
| Country of Origin | CHINA |
| Voltage | 125V |
|---|---|
| UL Standard | UL498 |
| UL Listed | Yes |
| CSA Listed | No |
| Mounting Type | Box |
| Wire Gauge Compatibility | #10-#14 AWG solid or stranded copper wire |
| Number of Gangs | 1 |
| Outlet Type | Dead Front, GFCI |
| Color | White |
