Lutron RRD-H6BRL-BL RadioRA 2 Hybrid 6-Button Wall Keypad Dimmer 450W 120V Black
- MPN: RRD-H6BRL-BL
- UPC: 027557868778
- PPN: LUT-RRD-H6BRL-BL
- UNSPSC: 39122206
CAD
$494.81
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
RadioRA 2 Hybrid 6-Button Wall Keypad Dimmer 450W 120V Black
Features
- 6 button with raise/lower keypad and 450W/450VA two-wire or neutral-wire dimmer (Incandescent/Halogen/Magnetic Low Voltage), 120V
- Great for retrofit applications since they eliminate the need to install two separate devices
- Connecting the neutral wire to a Hybrid keypad allows a lower minimum load to be used
- Normal keypad operations will be available if the attached load is not installed or if the lamp is burned out
- Can be controlled as part of a lighting control system and incorporates advanced features such as fade on/fade off and rapid full on
- Easy-to-use buttons, plus a unique backlit engraving option that makes them readable any time of the day or night
- Buttons are rounded, allowing engraving to be displayed at an upward angle, increasing readability
- Front accessible service switch for safe lamp replacement
- Wallplate sold separately.
Documentation & Downloads
Specifications
Key Specifications
- NETXASC
- 6 button with raise/lower keypad and 450W/450VA two-wire or neutral-wire dimmer (Incandescent/Halogen/Magnetic Low Voltage), 120V. Great for retrofit applications since they eliminate the need to install two separate devices. Connecting the neutral wire to a Hybrid keypad allows a lower minimum load to be used. Normal keypad operations will be available if the attached load is not installed or if the lamp is burned out. Can be controlled as part of a lighting control system and incorporates advanced features such as fade on/fade off and rapid full on. Easy-to-use buttons, plus a unique backlit engraving option that makes them readable any time of the day or night. Buttons are rounded, allowing engraving to be displayed at an upward angle, increasing readability. Front accessible service switch for safe lamp replacement. Wallplate sold separately.
- NETXPOL
- Lutron Online Policy - GATED
- NETXMB2
- At the press of a keypad button, lights fade ON or OFF to desired levels and shades/draperies open or close to desired positions.
- NETXMB4
- Prepaid engraving included. Redeemable for one engraved replacement kit.
- NETXMB6
- Internal dimmer can be assigned to any button on the Hybrid Keypad and can be programmed to be controlled by any Keypad.
- NETXMB8
- Can be installed in either single location or multi-location (with remote dimmer) installations
- Actuator
- Push-button
- Color
- Black
- Enclosure
- Plastic
- Frequency Rating
- 50 to 60 Hz
- Material
- Plastic/Metal
- Number Of Poles
- 1
- Size
- 4.69 x 2.94 in | 119 x 75 mm
- Voltage Rating
- 120 VAC
NETXCATRadioRA 2 Hybrid Keypad, 6-button with raise/lower keypad and 450W/450VA two-wire or neutral-wire dimmer (Incandescent/Halogen/Magnetic Low Voltage), 120V, in black
NETXMB1Keypad buttons are programmable to select scene or room preset levels or positions.
NETXMB3Adjustable backlight intensity.
NETXMB5Internal dimmer is assigned to top button by default. Tap top button to toggle load ON / OFF
NETXMB7Can be installed in two-wire or neutral wire applications
Class CodeED-LSR
ApplicationLighting Control
ConnectionWire Leads
Environmental Conditions0 to 90% humidity, non-condensing. Indoor use only.
InsulationPlastic
MountingWallbox
Operating Temperature32 to 104 F | 0 to 40 C
TypeHybrid keypad dimmer
Wattage450 W
