Hubbell Premise Wiring S1R10CBF050 Recessed 10 Inch Bottom Feed Plate, Fire Rated, 2 Inch Width
- MPN: S1R10CBF050
- UPC: 783585548012
- PPN: HBL-S1R10CBF050
- UNSPSC: 39121328
CAD
$92.08
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Fire Rated Poke Throughs, Recessed 10" Series, Bottom Feed Plate, Center, 1/2" EMT
Features
- Bottom Feed Plates are Required to Maintain S1R10PTFIT Fitting Fire Rating
- Varity of Feed Plates Offers Installation Flexibility
- Includes Necessary Mounting Hardware
- Standard Product
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- United States
- Core Hole
- 10 Inch
- Industry Standard(s)
- cULus Listed
- Size
- Standard Sized Product
- Cable Entry
- Through Cover
- Finish
- Natural
- Mounting
- Screw Mount
- Standard
- cULus Listed
- Type
- 10" Recessed Rated Poke Through Accessories
- Accessory Type
- Bottom Feed Plate
- Finish Type
- Natural
- Style
- Accessories
- Harmonization Code
- 7326908688
- MSDS Flag
- No
- Base Unit of Measure
- EA
- Carton - Gross Weight per Pack
- 7.800 lb.
- Carton - Pack Description
- Carton
- Carton - Total Units
- 30 EA
- NAICS Code
- 3359326106
Application - For Use OnConcrete
Width2.000 in
Plate Style1-Gang Center
Application10" Fire-Rated Poke-Through Series
ColorMetallic
Material050 Meunt
Special FeaturesStandard Product
Sub BrandSystemOne Recessed
General Literature Asset 1 Display TextHubbell SystemOne Recessed Fire-Rated Poke-Throughs
Construction Material - Main050 Meunt
Mounting TypeScrew Mount
Freight Class Code06111001
Image Actual Or RepresentativeA
ConstructionFabricated
BOX SIZE7.500x11.200x12.200 (in)
Carton - Number of Sub Packs30
Carton - SCC-14 Next Lower Level Sub Pack00783585548012
Case Weight7.900 lb.
