Schneider Electric S434220 Circuit breaker accessory, BSCM V2, replacement
- MPN: S434220
- PPN: SCH-S434220
CAD
$1876.32
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Square D PowerPacT H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. Molded case circuit breakers are available with either thermal-magnetic or Micrologic electronic trip units. The optional BSCM Breaker Status & Control Module is used to acquire device status indications and control the communicating remote-control function. It includes a memory used to manage the maintenance indicators. The BSCM can be used to carry out communicating remote control operations using the communicating motor operator (open, close and reset) in different modes (manual, auto). The BSCM is installed inside the circuit breaker behind the front cover. It is connected to external Ethernet or Modbus interfaces (IFE/IFM) via the NSX cord terminal block. The BSCM operational voltage is 24VDC. This unit is UL/CSA certified.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- United States
Depth30 mm
Communications & Management Attributes
- Communication Network Type
- Modbus, Modbus Serial line slave 9.6...38.4 kbauds
Important Information Attributes
- Persona Type Ids
- LC, OM, OM8, PB
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Function Of Module
- control circuit breaker, get breaking status, gateway for Modbus-SL connected devices
- Range Of Product
- ComPacT NSX100...250, ComPacT NSX400...630, PowerPact H, PowerPact J, PowerPact L
- Local Publishable Date
- 2025-11-13
- Return Indicator
- Y
- Stock Policy
- 1
- Eoli Availability Display
- No need of specific recycling operations
- Reach Full Compliance Status Id
- CONTAINS_SVHC
- Rohs Eur In Scope
- Yes
- Rohs Eur Conformity Date
- 2420
- China Rohs In Scope
- No
- With Recycled Cardboard
- Yes
- Product Contributes To Saved And Avoided Emissions
- No
- Tier
- 1
- Function Option
- Standard
- Current Consumption
- 40 mA 24 V DC room temperature
- Device Short Name
- BSCM MBSL/ULP
- Mounting Mode
- by clips
- Product Availability
- Stock - Normally stocked in distribution facility
- Returnability
- Yes
- Height Nominal
- 34 mm
- Certificate Agency
- UL
- Connections - Terminals
- plug-in connector
- Nbr. Of Units In Pkg.
- 1
- Take-back
- No
- Customs Code
- 8517620090
Persona Type NamesContractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder
Market SegmentationCommercial, Industrial
RangeComPacT, PowerPact
Local Data StatusPublishable
Pre Comm Date2024-09-09
Stocking FlagY
Scope PerimeterOutside of Europe
Reach Full Compliance StatusReference contains Substances of Very High Concern above the threshold
Reach Compliance DirectiveReference contains Substances of Very High Concern above the threshold
Rohs Eur StatusCompliant By Exemption
Rohs Eur Full Compliance StatusCompliant By Exemption
China Rohs Label7
Without Single Use PlasticNo
Tier Id1
Function Option IdSTANDARD
Product Kit IdentifierN
Device Applicationcommunication
Energy Efficiency OptimizedFalse
Power Consumption In W0.96 W
Product Or Component Typecommunication module
Sustainable PackagingNo
Width Nominal28 mm
[Us] Rated Supply Voltage24 V DC
Halogen-free StatusHalogen free plastic parts product
Package Weight(Lbs)81.647 g
Warranty (In Months)18
Environment Attributes Main
- China Rohs Regulation
- Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
- Ambient Air Temperature For Storage
- -40-85 °C, -40-85 °C
- Halogene Performance
- Halogen free plastic parts product
- Mercury Free
- Yes
- Halogen Content Performance
- Halogen free plastic parts product
- Packaging Without Single Use Plastic
- No
- Relative Humidity
- 5-85 % 55-55 °C without condensation
Ambient Air Temperature For Operation-25-70 °C, -25-70 °C
Take BackNo
Recycled Metal Content At Cr Level0 %
Eu Rohs DirectiveCompliant By Exemption
Packaging Made With Recycled CardboardYes
Reach RegulationReference contains Substances of Very High Concern above the threshold
General Attributes
- Range Of Product
- ComPacT NSX100...250, ComPacT NSX400...630, PowerPact H, PowerPact J, PowerPact L
Product Or Component Typecommunication module
Input Attributes
- Input Voltage
- 24 V DC +/- 10 %
