Schneider Electric NSYCUACC028DG Retrofit kit for CU Slim 3,2kW to Connected Cooling Unit, Climasys CU, surface mounted

MPN: NSYCUACC028DG
PPN: SCH-NSYCUACC028DG
UNSPSC: 31162313

$1003.71

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

This Accessory is a Retrofit kit for CU Slim to Side Connected Cooling Unit. It's made with galvanized steel and its color is RAL 7035. Its dimensions (HxWxD) are 1712x580x1.5 mm. Its IP index is IP55.

Features

Recommended to save time and ease the installation of a new Cooling unt in place of an existing Cooling Unit
Easy installation
Kit to mount in surface position a new Connected Cooling Unit in place of an existing Schneider Slim CU
RAL 7035 grey

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Malta
Width	22.83 in

Height	67.4 in
Depth	1.5 mm

Physical Attributes

Color	Gray RAL 7035)

Important Information Attributes

Device Composition	1 adaptor sides of enclosure, fixing elements, gasket
Local Publishable Date	2026-08-19
Weee Scope	Out
Reach Full Compliance Status	Free of Substances of Very High Concern above the threshold
Reach Compliance Directive	Free of Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	Yes
Product Kit Identifier	N
Enclosure Mounting	surface
Material	galvanized steel
Product Availability	Non-Stock - Not normally stocked in distribution facility
Product Name	CU
Range	ClimaSys
Returnability	No
Height Nominal	1712 mm
Width Nominal	580 mm
Accessory / Separate Part Type	mounting panel
Customs Code	7326908688

Local Data Status	Publishable
Return Indicator	N
Scope Perimeter	At least in Europe
Reach Full Compliance Status Id	NOT_CONTAINING_SVHC
Rohs Eur In Scope	No
Rohs Eur Conformity Date	2327
China Rohs In Scope	No
With Recycled Cardboard	No
Product Contributes To Saved And Avoided Emissions	No
Device Application	adapt old offer
Fixing Mode	by bolt
Mounting Location	side of enclosure
Product Destination	side-mounting cooling unit 3200 W 3200 W
Product Or Component Type	retrofit kit
Range Of Product	ClimaSys
Sustainable Packaging	No
Height Useful	1712 mm
Width Real	580 mm
Nbr. Of Units In Pkg.	1
Warranty In Months	18

Environment Attributes Main

China Rohs Regulation	Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
Reach Free Shvc	Yes
Eu Rohs Directive	Compliant
Packaging Made With Recycled Cardboard	No
Reach Free Of Svhc	Yes

Take Back	No
Recycled Metal Content At Cr Level	0 %
Ip Degree Of Protection	IP55
Packaging Without Single Use Plastic	Yes
Reach Regulation	Free of Substances of Very High Concern above the threshold
