Weidmuller 2422480000 SAID-M12B-8-9SMT
- MPN: 2422480000
- PPN: WDM-2422480000
CAD
$8.16
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Built-in plugs, M12, Socket connector, Number of poles: 8
Documentation & Downloads
Specifications
Approvals
- ROHS
- Conform
Dimensions And Weights
- Net weight
- 3.52 g
Technical Data Of Pcb Plug-In Connector
- Coding
- A
- Number of poles
- 8
- Rated voltage
- 30 V
- Rated current
- 4 A (4- and 5-pole) / 2 A (8-pole)
- Protection degree
- IP67
- Housing main material
- LCP
- Tightening torque
- M12: 0.8 Nm
- Pollution severity
- 3 (2 within the sealed area)
- Contact material
- CuZn
- Material of the flange-mounted housing
- Nickel-plated CuZn
HousingsM12 socket
Shield connectionNo
Rated voltage (text)250 V (4-pole) / 60 V (5-pole) / 30 V (8-pole)
Temperature range-25…95 °C
Contact surfaceAu (Gold)
Connection threadM12
Insulation strength100 MΩ
Plugging cycles≥ 100
Lock nut materialNickel-plated CuZn
Material Data
- Contact material
- CuZn
Contact surfaceAu (Gold)
Classifications
- ETIM 6.0
- EC000438
- eClass 9.1
- 27-44-02-05
ETIM 7.0EC000438
eClass 10.027-44-02-23
System Parameters
- Insulation strength
- 100 MΩ
- Pin series quantity
- 1
- Protection degree
- IP67
Number of poles8
Plugging cycles≥ 100
Environmental Product Compliance
- REACH SVHC
- Lead 7439-92-1
