Hubbell Wiring Device-Kellems P15DH485C10 Panel-Safe DH485 Receptacle 15A 125V NEMA 12/4 2.5 Inch Depth
- MPN: P15DH485C10
- UPC: 783585093482
- PPN: HBL-P15DH485C10
- UNSPSC: 32151903
CAD
$1638.20
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Signal And Control, Panel Safe, 1) DH485, 1) 15A 125V Receptacle, NEMA 12/4 Enclosure
Features
- Protective clear cover
- Overcurrent protection
- Finger-safe contacts
- Stainless steel snap latch
- Standard Product
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- United States
- Performance
- Electrical - Circuit Breaker - 3A;Electrical - Data Jack - Cat. 5e;Electrical - GFCI - Conforms to UL 943 2006 requirement;Electrical - In-Cabinet Receptacle - GFCI protected;Environmental - Enclosure - NEMA Type 4, 12 and NEMA Type 4X
- Color
- Gray, Clear
- Enclosure
- NEMA 12/4
- Special Features
- Standard Product
- Width
- 2.5 in
- General Literature Asset 1 Display Text
- Pulp & Paper Solutions
- Enclosure Type
- NEMA 12/4
- Description - Invoice
- PANEL SAFE W/15A/125V, DH485 PORT
- Harmonization Code
- 8537109170
- MSDS Flag
- No
- Material - Mounting Hardware
- Screw Mounting
- Base Unit of Measure
- EA
- Carton - Gross Weight per Pack
- 40.000 lb.
- Carton - Pack Description
- Carton
- Carton - Total Units
- 20 EA
- Lowest Level UOM
- Each
Industry Standard(s)CSA Certified;UL Recognized
Cable EntryPlug-In
Depth2.5 in
Height5.5 in
StandardCSA Certified;UL Recognized
Engineering Drawing 1 Display TextP15DH485C10 AutoCAD Drawing
General Literature Asset 2 Display TextPULP & PAPER SOLUTIONS
Class CodeA28
Freight Class Code06168002
Image Actual Or RepresentativeA
Sub Class CodeA28A300
MaterialComposite
BOX SIZE6.600x4.800x14.200 (in)
Carton - Number of Sub Packs20
Carton - SCC-14 Next Lower Level Sub Pack783585093482
Each - Pack DescriptionEach
NAICS Code335931A107
Certifications
- EU RoHS Indicator
- Yes
