Bryant AFP14 Single-Gang Keystone Wallplate, Angled, 4-Port, Light Almond, High-Impact Thermoplastic
- MPN: AFP14
- UPC: 662620803326
- PPN: HBL-AFP14
- UNSPSC: 39121704
CAD
$5.89
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Hubbell Premise Wiring's angled wall plates offer 45° jack and Audio/Video connector mounting along with TIA/EIA-606A station labeling ability and the traditional features of HPW's standard flush wall plates. The design of the AFP plate positions the patch cord down at an angle of 45°, which provides additional protection against exceeding the minimum bend radius. The 45° angle also protects the patch cord/jack connection from being damaged from office furniture. AFP plates include 2 smooth locations for adhesive labels or can be fitted with optional snap in clear label covers and paper inserts.
Features
- Fits all Hubbell keystone connections (AV, data and fiber)
- Secure
- Requires removal to access connectivity
- Angled
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Puerto Rico
- Industry Standard(s)
- RoHS Compliant;UL and cUL Listed 1863
- Size
- Standard
- Application
- Areas with Capacity Bend Radius restrictions
- Orientation
- Vertical
- Standard
- RoHS Compliant;UL and cUL Listed 1863
- Number Of Ports
- 4
- Description - Invoice
- PLATE, ANG,1-G,4P,OW
- Harmonization Code
- 3925900000
- MSDS Flag
- No
- Sub Class Code
- HPWALL2
- Material
- High-Impact Thermoplastic (UL 94V-0)
- Base Unit of Measure
- EA
- Carton - Gross Weight per Pack
- 1.450 lb.
- Carton - Pack Description
- Carton
- Carton - Total Units
- 20 EA
- Case Weight
- 31.250 lb.
- Lowest Level UOM
- Each
- Pallet Height
- 36.600 in
- Pallet Weight
- 375.000 lb.
Width2.680 in
Label Field AvailableYes
Standards - RoHS Compliance StatusCM
ColorLight Almond/Office White
Special FeaturesAngled
TypeKeystone
StyleAngled
Freight Class Code06168002
Image Actual Or RepresentativeA
Replaced Catalog NumberWPP300
Material - Mounting HardwareScrew
Number of Gang(s)1-Gang
BOX SIZE5.100x8.200x5.500 (in)
Carton - Number of Sub Packs20
Carton - SCC-14 Next Lower Level Sub Pack662620803326
Case - Total Units360 EA
Each - Pack DescriptionEach
Pallet - GTIN - Package70662620803325
Pallet Length48.000 in
Pallet Width40.000 in
Certifications
- EU RoHS Indicator
- Yes
