Mersen

Mersen L082488 Protistor® 10x28 aR Fuse 250VAC 10A Grit 200kA Breaking Capacity

Protistor® 10x28 aR Fuse 250VAC 10A Grit 200kA Breaking Capacity
  • MPN: L082488
  • PPN: FER-L082488

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$61.65/ EA

Description

Extremely high breaking capacity fuses: Protection of power semiconductors as per IEC standard 60269-1 and -4 250 V voltage rating as per IEC 33 gR class as per VDE 636-23 and IEC 60269.4 Design without indicator

Specifications

Specifications

Rated voltage AC IEC
250 V
ROHS Compliant
Yes
Speed/Characteristic
gR
Mounting
Bolted
Melting I2t
2.4 A²s
Connection/Terminal Material
Copper
Body/Insulating Material
Ceramic
Length
1.8 in
Ampere Rating10 A
AC or DCAC
Fuse Size10x28
Clearing I2t At Rated Voltage20 A²s
AC Max I.R./Breaking Capacity: I1200 kA
Connection/Terminal TypeL Brackets
Power Dissipation at Rated Current Value2.1 W
Weight0.023 lb
