SolaHD STV25K10S SolaHD™ STV25K DIN Rail Series Surge Protective Devices - PN STV25K10S

SolaHD™ STV25K DIN Rail Series Surge Protective Devices - PN STV25K10S
  • MPN: STV25K10S
  • PPN: SHD-STV25K10S

Spec sheet

Loading compare button...

Available to Order

Company Stock:

0

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Looking to buy a large quantity?

To view product inventory

CAD$483.97/ EA

Description

STV25K DIN Rail Series Surge Protective Devices offer dedicated, point-of-use surge protection to shield equipment against damaging transients. These surge protectors are ideal for installation in electronic control cabinets found in harsh industrial environments. They provide 25,000 Amps of surge protection on all electrical paths, sinewave tracking, LED status indication and form C dry contacts.

Features

  • cRUus, RoHS
  • Compact and narrow design maximizes panel space
  • Low clamping levels for more effective protection
  • Easy access terminal screws for quick mounting and installation
  • 25,000 amps of surge protection
  • Sinewave tracking and all mode protection provide consistent and reliable protection on all electrical paths
  • Thermal fusing prevents MOV overheating caused by excessive current levels

Specifications

Specifications

Amperage
20
Noise Attenuation, Common Mode
40 dB Min
Input Voltage Range
120, 240 Vac
Operating Temperature
-40°C to +60°C
Mounting
DIN Rail Mount (Chassis Mount Optional)
Noise Attenuation, Nominal Mode50 dB Min
Hertz47-63 Hz
Number of PhasesSingle Phase
Status IndicatorGreen LED, Form C Contacts
