StreamLine Modular Electronic Sounder, High Output, UL and cUL, Gray, Base Sold Separately
Federal Signal

Federal Signal SLM800GY StreamLine Modular Electronic Sounder, High Output, UL and cUL, Gray, Base Sold Separately

  • MPN: SLM800GY
  • UPC: 782979233268
  • PPN: FDS-SLM800GY
  • UNSPSC: 32151501

CAD

$329.82

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Description

Model slm800 is a high-output multifunctional electronic sounder developed with a multiple input technology that can produce two different tones (one per channel), controllable via wiring selection.There are 64 unique tones to select from across two switches (32 tones per switch). The volume of the tone is adjustable between 65-115 dBa @ 1m at three output levels (high, medium and low) through an integrated button. Model slm800 body material is a self-extinguishing polycarbonate material with high impact and UV resistance suitable for outdoor applications.* Recent changes have been made to this product line. Previous product data can be found in the documents below or by visiting slm Documents or Rev A Tones.

Features

  • Compatible with 12-24VAC/DC or 120-240VAC*
  • PLC compatible with PNP and NPN connections
  • Choice of 64 selectable tones (32 per input selectable via DIP switch)
  • Produces two tones at three adjustable tone levels
  • Adjustable volume between 89 dBa to 105 dBa @ 10' (99-115 dBa @ 1m)
  • Five mounting base options
  • Type 3R, IP65 enclosure
  • CE Certified
  • UL and cUL Listed

Documentation & Downloads

Specifications

Key Specifications

Country of Origin
Italy
Body Color
Gray
dBa 1 Meter
99-115 (12-24VAC/DC), 99-111 (120-240VAC)
Availability
In Stock - Ships in 2 Bus Days
Operating Temp.
-40˚ to +131˚F (-40˚ to +55˚C)
Audible Signals Body Color
Gray
Height
3.44 in, 8.7376 cm
Weight1.19 lbs
Certification ListingCE, UL, cUL
dBa 10 Ft89-105 (12-24VAC/DC), 89-101 (120-240VAC)
Mount TypePipe, Surface, Wall
Operating Voltage12-24VAC-DC, 120-240VAC
Depth3.44 in, 8.7376 cm
Width3.9 in, 9.906 cm
