Telemecanique Sensors

Telemecanique Sensors SM952A134000 Ultrasonic dual-level sensor SM, 30 mm barrel, 12-24 V DC, alarm, discrete output type NPN, discrete output function 1 NO

  • MPN: SM952A134000
  • PPN: TES-SM952A134000

CAD

$1001.47

/ EA

Available to Order from Manufacturer

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Description

Ultrasonic dual-level sensor SM, 30 mm barrel, 12-24 V DC, alarm, discrete output type NPN, discrete output function 1 NO

Documentation & Downloads

Specifications

Key Specifications

Indivisible sale quantity1
Commercial statusCommercialised

Complementary

Minimum size of detected objectCylinder diameter 1.6 mm - up to 305 mm sensing distance
Current consumption100 mA

Main

Range of productHyde Park
Series nameSuperprox 900
MaterialPlastic
Type of sensing windowAdjustable
Wiring technique4-wire
Discrete output typeNPN
Electrical connectionMale connector M12 4 pins
Enclosure materialULTEM
Sensor typeUltrasonic sensor
Sensor designCylindrical M30
Type of output signalDiscrete
Discrete output function1 NO
Rated supply voltage (Us)12...24 V DC with overload and short-circuit protection
ISO threadM30 x 1.5
Product specific applicationDual-level - alarm
Front materialSilicone rubber

Environment

IP degree of protectionIP67
Product certificationsUL
Vibration resistance+/-1 mm conforming to IEC 60068-2-6 (f = 10-55 Hz)
MarkingCE
NEMA degree of protectionNEMA 4X (indoor use only)
Shock resistance30 gn in all 3 axes for 11 ms conforming to IEC 60068-2-27
Ultrasonic dual-level sensor SM, 30 mm barrel, 12-24 V DC, alarm, discrete output type NPN, discrete output function 1 NO
