Burndy PAT444ST3U03A2 T3 Tech 11-Ton Dieless Battery Crimper, 3Ah, Hard Case, 14.95 in x 3.25 in x 16.9 in
- MPN: PAT444ST3U03A2
- UPC: 621945624573
- PPN: BUR-50112553
- UNSPSC: 27112750
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
PATRIOT® Series, T3 Technology 11-Ton Dieless Battery Crimper, C-Head, Uncovered, Hard Case, Makita (2) 3.0Ah 18V Li-Ion Batteries, 120V-AC Charger
Features
- TRACK crimp locations with onboard GPS - BURNDY Exclusive!
- TRACE individual crimps with comments, photos, and output force validation
- TRANSMIT via Bluetooth® technology and sync data to the cloud
- C-Head for easy access and increased flexibility
- Dieless System with range taking capability
- Bright LED worklight and Red/Green LED to validate output force
- Improved ergonomic design with more balance and better grip to reduce user fatigue
- Accepts 2.0Ah-6.0Ah Makita Lithium-ion Batteries
Specifications
Key Specifications
- Country of Origin
- United States
- ChannelSightWidgetId
- 705
- Crimp Force Capacity
- 11 ton
- Die Type
- Dieless
- Height
- 16.9 in
- Operating Voltage
- 18 VDC
- Product Type
- 11-Ton Single Indenter
- Battery
- 3.0Ah 18V Li-Ion (Accepts 2.0Ah-6.0Ah Makita LI Batteries)
- Size
- 14.95 in x 3.25 in x 16.9 in
- Warranty
- 5 year limited warranty, Lifetime warranty on INFINITY DRIVE®, 3 year warranty on batteries and charger
- Width
- 3.25 in
- ARRA Compliant
- Contact Manufacturer
- Class Code
- B82
- Freight Class Code
- 16027000
- Image Actual Or Representative
- A
- Order Multiple
- 1 EA
- Sub Class Code
- B82B82B
- Series
- PATRIOT® Series
- Base Unit of Measure
- EA
- Carton - SCC-14 Next Lower Level Sub Pack
- 00621945624573
- Each - Pack Description
- Each
- NAICS Code
- 3339911151
Application - For Use OnCopper, Aluminum, ACSR Terminals and Splices, Cable Pulling Heads
Container TypeHard Case
Description - SlangT3 Tech, BURNDY T3, PATRIOT T3, T3, PAT444S, 444S, 444ST3, 11-Ton, Dieless C-head
Dimensions14.95 in x 3.25 in x 16.9 in
Length14.95 in
Power Source120V-AC Charger
ApplicationCrimping
Crimping Force11 Tons
TypeCrimper
Weight15.20 lb.
Battery Type3.0Ah 18V Li-Ion (Accepts 2.0Ah-6.0Ah Makita LI Batteries)
Certification AgencyProposition 65
Description - InvoiceT3 Tech 11T Dieless C-Head, 3Ah, AC, HC
Harmonization Code8467290090
MSDS FlagNo
Stock IndicatorS - Shelf Stock
Crimping RangesCopper: #4 AWG - 1000 kcmil; Aluminum: #4 AWG - 1000 kcmil; ACSR: #4 AWG - 556.5 kcmil
Tool TypeBattery
BOX SIZE(in)
Each - Number of Sub Packs1
Lowest Level UOMEach
Certifications
- Buy American Compliant
- Contact Manufacturer
