Burndy PAT750T3U03A2 Battery Crimper 12-Ton, 3Ah Li-Ion, 1.65 Inch Jaw Width, AC, Hard Case
- MPN: PAT750T3U03A2
- UPC: 621945558939
- PPN: BUR-50102068
- UNSPSC: 27112750
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
PATRIOT® Series, T3 Technology 12-Ton Battery Crimper, C-Head, Uncovered, Hard Case, Makita (2) 3.0Ah 18V Li-Ion Batteries, 120V-AC Charger
Features
- TRACK crimp locations with onboard GPS - BURNDY Exclusive!
- TRACE individual crimps with comments and output force validation
- TRANSMIT via Bluetooth® technology and sync data to the cloud
- C-head with 1.65" jaw opening with 355° head rotation
- Used with U dies
- Bright LED worklight and Red/Green LED to validate output force
- Improved ergonomic design with more balance and better grip to reduce user fatigue
- Patented T-Track alignment guide for HYGROUND® as well as other asymmetrical connectors
- Accepts 2.0Ah-6.0Ah Makita Lithium-ion Batteries
Specifications
Key Specifications
- Country of Origin
- United States
- ChannelSightWidgetId
- 705
- Crimp Force Capacity
- 12 ton
- Die Type
- U Die
- Height
- 14.75 in
- Operating Voltage
- 18 VDC
- Product Type
- 12-Ton
- Application
- Crimping
- Size
- 15.75 in x 3.25 in x 14.75 in
- Warranty
- 5 year limited warranty, Lifetime warranty on INFINITY DRIVE®, 3 year warranty on batteries and charger
- Width
- 3.25 in
- Jaw Width
- 1.65 in
- Class Code
- B82
- Harmonization Code
- 8467290090
- Sub Class Code
- B82B82B
- Crimping Ranges
- Copper: #14 sol. - 750 kcmil; Aluminum: #8 sol. - 750 kcmil; ACSR: #4 AWG - 556.5 kcmil; Ground Rod: 1/2" - 1" diameter
- Tool Type
- Battery Actuated Crimper, T3 Technology
- BOX SIZE
- (in)
- NAICS Code
- 3339911151
Application - For Use OnTension Sleeves, Taps, Aerial Cable, Terminals & Splices, HYGROUND® Compression Grounding
Container TypeHard Case
Description - SlangT3 Tech, BURNDY T3, PATRIOT T3, T3, PAT750, 750, 12-Ton, U-die Crimper
Dimensions15.75 in x 3.25 in x 14.75 in
Length15.75 in
Power Source120V-AC Charger
Trade NamePATRIOT®
Battery3.0Ah 18V Li-Ion (Accepts 2.0Ah-6.0Ah Makita LI Batteries)
TypeCrimper
Weight14.85 lb.
Battery Type3.0Ah 18V Li-Ion (Accepts 2.0Ah-6.0Ah Makita LI Batteries)
Certification AgencyProposition 65
Freight Class Code16027000
Image Actual Or RepresentativeA
Recharge Time0.5 hr
SeriesPATRIOT® Series
Base Unit of MeasureEA
Carton - SCC-14 Next Lower Level Sub Pack00621945558939
